Superwinch / S104103
Part #: S104103
UPC: 022705006101
Loading...
Notify me when this item is in stock.
Description: SH1000i Hoist; 1000 lbs; 12 VDC; Standard Drum; No Rope; 1.8 hp; Automatic Spring Brake; 3-Stage Planetary; 138:1 Gear Ratio; No Fairlead;
Description:
Description
Superwinch's SH1000i Hoist is a great solution for a wide variety of jobs. Designed to lift and hold a full 1,000 lbs. payload, the SH1000i Hoist is an outstanding choice for do-it yourself mechanics, handyman work, and an array of construction jobs and other tasks. Works anywhere you have a 12 volt battery source, to power the robust 1.8 HP 12V DC motor. The compact design is powerful and built with a limited 2 year warranty.
Features & benefits
- 1000 lbs. Capacity
- Minimum Rope Size Of 3/16 in. [4.76mm]
- Ip66 Protection From Water And Dust
- 2-Hole Mounting Bolt Pattern 3.1 in. On Center
- Gray Powder Coat Finish
- 1.8 hp 12V DC Motor
- Permanent Magnetic Motor Provides Dynamic Breaking
- 3-Stage Planetary Gearing w/138:1 Ratio
- Standard Drum
- Minimum Electric Cable Size Of 8 AWG
- 4:1 Safety Factor
Specifications
- GTIN
- 00022705006101
- Weight
- 20 lb
- Height
- 7 in
- Length
- 16 in
- Width
- 7 in
- Life cycle
- Available to Order
- AAM brand code
- SPW
- Warehouse brand code
- SPW
- AAIA brand code
- BGFJ
Attributes
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Rated Single Line Pull (lbs.)
- 1000
- Type
- Standard
- Voltage
- 12 DC
Fitment status
This product is universal and will fit your application.
