Silv-O-lite · 3513.040
Part #: 3513.040
UPC: 800745130495
Log in for inventory
Notify me when this item is in stock.
Description: Silv-O-Lite ReMan Pro Piston - GM 305ci/5.0L (V8)
Description:
Description
Silv-O-Lite ReMan Pro Piston - GM 305ci/5.0L (V8)
Features & benefits
- 305 engine using a 350 crank.
- Not OE weight.
- 3.125" diameter recess .095" deep.
- 4 valve reliefs.
Application summary
| Year | Make / model |
|---|---|
| 1977-1981 | Buick Century |
| 1991 | Buick Commercial Chassis |
| 1978 | Buick LeSabre |
| 1977-1980 | Buick Regal |
| 1982-1987 | Buick Regal |
| 1991 | Buick Roadmaster |
| 1977-1979 | Buick Skylark |
| 1991-1992 | Cadillac Brougham |
| 1981 | Chevrolet Bel Air |
| 1987 | Chevrolet Blazer |
| 1977-1986 | Chevrolet C10 |
| 1977-1979 | Chevrolet C10 Suburban |
| 1981-1986 | Chevrolet C10 Suburban |
| 1988-1995 | Chevrolet C1500 |
| 1977-1978 | Chevrolet C20 |
| 1981-1986 | Chevrolet C20 |
| 1977-1979 | Chevrolet C20 Suburban |
| 1981-1986 | Chevrolet C20 Suburban |
| 1988-1995 | Chevrolet C2500 |
| 1978 | Chevrolet C30 |
| 1976-1992 | Chevrolet Camaro |
| 1977-1993 | Chevrolet Caprice |
| 1991-1992 | Chevrolet Commercial Chassis |
| 1980 | Chevrolet Corvette |
| 1976-1987 | Chevrolet El Camino |
| 1977-1995 | Chevrolet G10 |
| 1980-1995 | Chevrolet G20 |
| 1978-1979 | Chevrolet G30 |
| 1982 | Chevrolet G30 |
| 1985 | Chevrolet G30 |
| 1977-1985 | Chevrolet Impala |
| 1977-1978 | Chevrolet K10 |
| 1981-1986 | Chevrolet K10 |
| 1977-1979 | Chevrolet K10 Suburban |
| 1981 | Chevrolet K10 Suburban |
| 1983 | Chevrolet K10 Suburban |
| 1986 | Chevrolet K10 Suburban |
| 1988-1995 | Chevrolet K1500 |
| 1977-1978 | Chevrolet K20 |
| 1985 | Chevrolet K20 |
| 1977-1978 | Chevrolet K20 Suburban |
| 1985-1986 | Chevrolet K20 Suburban |
| 1988-1995 | Chevrolet K2500 |
| 1977-1986 | Chevrolet K5 Blazer |
| 1978-1983 | Chevrolet Malibu |
| 1976-1988 | Chevrolet Monte Carlo |
| 1976-1979 | Chevrolet Monza |
| 1976-1979 | Chevrolet Nova |
| 1979 | Chevrolet P10 |
| 1987 | Chevrolet R10 |
| 1987 | Chevrolet R10 Suburban |
| 1987-1988 | Chevrolet R20 |
| 1987 | Chevrolet V10 |
| 1977-1978 | GMC C15 |
| 1977-1978 | GMC C15 Suburban |
| 1979-1986 | GMC C1500 |
| 1988-1995 | GMC C1500 |
| 1979 | GMC C1500 Suburban |
| 1981-1986 | GMC C1500 Suburban |
| 1977-1978 | GMC C25 |
| 1977-1978 | GMC C25 Suburban |
| 1980-1986 | GMC C2500 |
| 1988-1995 | GMC C2500 |
| 1982-1986 | GMC C2500 Suburban |
| 1978 | GMC C35 |
| 1986 | GMC C3500 |
| 1978-1987 | GMC Caballero |
| 1977-1978 | GMC G15 |
| 1979-1995 | GMC G1500 |
| 1981-1995 | GMC G2500 |
| 1977-1987 | GMC Jimmy |
| 1977-1978 | GMC K15 |
| 1977-1978 | GMC K15 Suburban |
| 1981-1986 | GMC K1500 |
| 1988-1995 | GMC K1500 |
| 1979 | GMC K1500 Suburban |
| 1982 | GMC K1500 Suburban |
| 1977-1978 | GMC K25 |
Specifications
- GTIN
- 00800745130495
- Weight
- 16 lb
- Height
- 18 in
- Length
- 3.38 in
- Width
- 9 in
- Life cycle
- Available to Order
- AAM brand code
- SOL
- Warehouse brand code
- BCRJ
- AAIA brand code
- BCRJ
Attributes
- Base Number
- 3513
- Bore (in)
- 3.736
- Bore (mm)
- 94.9
- Bore Diameter
- 3.736
- Crown (cc)
- +12.9cc
- Crown Type
- DISH
- Eng. Disp Liters
- 5
- Eng. Disp. In.
- 305
- Eng. Disp. Liters
- 5
- Engine Family
- Chevy Small Block Gen I
- Engine Manufacturer
- GM
- Oil Ring Thickness
- 0.1875
- Oversize
- .040
- Oversized
- Yes
- Oversizes
- STD .020 .030 .040 .060
- Pin Configuration
- Offset
- Pin Number
- 0927x300A
- Pin Type
- Press
- Piston Head Type
- Dish
- Piston Material
- Cast 332 Alloy
- Piston Pin Outside Diameter
- .927
- Ring Pack
- 5/64, 5/64, 3/16
- Second Compression Ring Thickness
- 0.0781
- Sold As
- Complete Piston Set
- Top Compression Ring Thickness
- 0.0781
- Top Land
- .240
- Year From
- 1976
- Year Range
- 1976-1995
- Year To
- 1995
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1977-1981 Buick Century; 1991 Buick Commercial Chassis; 1978 Buick LeSabre; 1977-1980 Buick Regal; 1982-1987 Buick Regal; 1991 Buick Roadmaster; 1977-1979 Buick Skylark; 1991-1992 Cadillac Brougham; 1981 Chevrolet Bel Air; 1987 Chevrolet Blazer; 1977-1986 Chevrolet C10; 1977-1979 Chevrolet C10 Suburban; 1981-1986 Chevrolet C10 Suburban; 1988-1995 Chevrolet C1500; 1977-1978 Chevrolet C20; 1981-1986 Chevrolet C20; 1977-1979 Chevrolet C20 Suburban; 1981-1986 Chevrolet C20 Suburban; 1988-1995 Chevrolet C2500; 1978 Chevrolet C30; 1976-1992 Chevrolet Camaro; 1977-1993 Chevrolet Caprice; 1991-1992 Chevrolet Commercial Chassis; 1980 Chevrolet Corvette; 1976-1987 Chevrolet El Camino; 1977-1995 Chevrolet G10; 1980-1995 Chevrolet G20; 1978-1979 Chevrolet G30; 1982 Chevrolet G30; 1985 Chevrolet G30; 1977-1985 Chevrolet Impala; 1977-1978 Chevrolet K10; 1981-1986 Chevrolet K10; 1977-1979 Chevrolet K10 Suburban; 1981 Chevrolet K10 Suburban; 1983 Chevrolet K10 Suburban; 1986 Chevrolet K10 Suburban; 1988-1995 Chevrolet K1500; 1977-1978 Chevrolet K20; 1985 Chevrolet K20; 1977-1978 Chevrolet K20 Suburban; 1985-1986 Chevrolet K20 Suburban; 1988-1995 Chevrolet K2500; 1977-1986 Chevrolet K5 Blazer; 1978-1983 Chevrolet Malibu; 1976-1988 Chevrolet Monte Carlo; 1976-1979 Chevrolet Monza; 1976-1979 Chevrolet Nova; 1979 Chevrolet P10; 1987 Chevrolet R10; 1987 Chevrolet R10 Suburban; 1987-1988 Chevrolet R20; 1987 Chevrolet V10; 1977-1978 GMC C15; 1977-1978 GMC C15 Suburban; 1979-1986 GMC C1500; 1988-1995 GMC C1500; 1979 GMC C1500 Suburban; 1981-1986 GMC C1500 Suburban; 1977-1978 GMC C25; 1977-1978 GMC C25 Suburban; 1980-1986 GMC C2500; 1988-1995 GMC C2500; 1982-1986 GMC C2500 Suburban; 1978 GMC C35; 1986 GMC C3500; 1978-1987 GMC Caballero; 1977-1978 GMC G15; 1979-1995 GMC G1500; 1981-1995 GMC G2500; 1977-1987 GMC Jimmy; 1977-1978 GMC K15; 1977-1978 GMC K15 Suburban; 1981-1986 GMC K1500; 1988-1995 GMC K1500; 1979 GMC K1500 Suburban; 1982 GMC K1500 Suburban; 1977-1978 GMC K25; ...
