Silv-O-lite · 3342HCA-STDK1
Part #: 3342HCA-STDK1
UPC: 800745291875
Log in for inventory
Notify me when this item is in stock.
Description: Silvolite Piston Kit - Ford 6.2L Boss V8 2010-2017 with Rings
Description:
Description
Silvolite Piston Kit - Ford 6.2L Boss V8 2010-2017 with Rings
Features & benefits
- OEM Plus Replacement
- Hypereutectic alloy.
- Anodized crown and top ring groove.
- Floating pin.
- SOHC.
- Piston & Ring Kit
Application summary
| Year | Make / model |
|---|---|
| 2017-2019 | Ford E-350 Super Duty |
| 2017-2019 | Ford E-450 Super Duty |
| 2010-2014 | Ford F-150 |
| 2011-2022 | Ford F-250 Super Duty |
| 2011-2022 | Ford F-350 Super Duty |
Specifications
- GTIN
- 00800745291875
- Weight
- 18 lb
- Height
- 5.25 in
- Length
- 22.25 in
- Width
- 9.5 in
- Life cycle
- Available to Order
- AAM brand code
- SOL
- Warehouse brand code
- BCRJ
- AAIA brand code
- BCRJ
Attributes
- Alloy
- Cast 390 Hypereutectic Alloy
- Base Number
- 3342HCA
- Bore (in)
- 4.016
- Bore (mm)
- 102
- Compression Ratio
- 9.8:1
- Crown (cc)
- +2.8cc
- Crown Type
- Flat
- Cylinder Bore Diameter
- 4.016
- Eng. Disp. In.
- 397
- Eng. Disp. Liters
- 6.2
- Engine Family
- Ford Boss 6.2L V8
- Engine Manufacturer
- Ford
- Grade Type
- Regular
- Lock
- LR927A
- Make For Engine Family
- Ford
- Oe Assembly
- AL3Z-6108-K
- Oil Ring Thickness
- 2.5
- Oversize
- STD
- Oversized
- No
- Oversized Amount
- STD
- Oversizes
- STD .25mm .5mm .75mm 1.0mm
- Pin Configuration
- Offset
- Pin Diameter (in)
- 0.944
- Pin Diameter (mm)
- 24
- Pin Number
- .9448x2.440x205TW
- Pin Type
- Floating
- Piston Material
- Cast 390 Hypereutectic Alloy
- Piston Pin Outside Diameter
- 0.944
- Ring Pack
- 1.5mm, 1.5mm, 2.5mm
- Rod (in)
- 6.201
- Rod (mm)
- 157.5
- Second Compression Ring Thickness
- 1.5
- Sold As
- Complete Piston and Ring Kit
- Stroke (in)
- 3.74
- Stroke (mm)
- 95
- Top Compression Ring Thickness
- 1.5
- Top Land
- 0.225
- Uses Ring Set
- 4016HS8
- Year From
- 2010
- Year Range
- 2010-2017
- Year To
- 2017
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
2017-2019 Ford E-350 Super Duty; 2017-2019 Ford E-450 Super Duty; 2010-2014 Ford F-150; 2011-2022 Ford F-250 Super Duty; 2011-2022 Ford F-350 Super Duty
