Silv-O-lite · 3323HC-STDK1

Silv-O-lite 3323HC-STDK1

Part #: 3323HC-STDK1
UPC: 800745291714

Loading availability... Log in for inventory

Notify me when this item is in stock.

Brand: Silv-O-lite Series: Hypereutectic Flat Top Coated Skirt Piston and Ring Sets

Log in to order

Description: Silv-O-Lite Piston & Ring Kit - Ford 330ci/5.4L (V8)

Description

Silv-O-Lite Piston & Ring Kit - Ford 330ci/5.4L (V8)

Features & benefits

- Hypereutectic.
- Flat top.
- .040" offset floating pin.
- Coated skirts.
- Piston & Ring Kit

Application summary

Year	Make / model
2005	Ford F-250 Super Duty
2005	Ford F-350 Super Duty
2006-2010	Ford Lobo

Specifications

GTIN: 00800745291714
Weight: 11 lb
Height: 5.25 in
Length: 17.75 in
Width: 9.75 in
Life cycle: Available to Order
AAM brand code: SOL
Warehouse brand code: BCRJ
AAIA brand code: BCRJ

Attributes

Alloy: Cast 390 Hypereutectic Alloy
Base Number: 3323HC
Bore (in): 3.5512
Bore (mm): 90.2
Compression Ratio: 9.8:1
Crown (cc): 0
Crown Type: Flat
Cylinder Bore Diameter: 3.5512
Eng. Disp. In.: 330
Eng. Disp. Liters: 5.4
Engine Family: Ford Modular V8
Engine Manufacturer: Ford
Grade Type: Regular
Lock: SRW-008
Make For Engine Family: Ford
Oe Assembly: 3L3Z-6108-CC
Oil Ring Thickness: 3
Oversize: STD
Oversized: No
Oversized Amount: STD
Oversizes: STD .25mm .5mm .75mm 1.0mm
Pin Configuration: Offset
Pin Diameter (in): 0.866
Pin Diameter (mm): 22
Pin Number: 11-33516
Pin Type: Floating
Piston Material: Cast 390 Hypereutectic Alloy
Piston Pin Outside Diameter: 0.866
Ring Pack: 1.5mm, 1.5mm, 3.0mm Shallow Oil Groove
Rod (in): 6.657
Rod (mm): 169.1
Second Compression Ring Thickness: 1.5
Sold As: Complete Piston and Ring Kit
Stroke (in): 4.165
Stroke (mm): 105.8
Top Compression Ring Thickness: 1.5
Top Land: 0.24
Uses Ring Set: 3551CD8
Year From: 2006
Year Range: 2006-2011
Year To: 2011

Fitment status

Select a vehicle or engine to see whether this part applies to your application.

Application summary

2005 Ford F-250 Super Duty; 2005 Ford F-350 Super Duty; 2006-2010 Ford Lobo

Resources

Retail View

Year	Make/Model
2005	Ford F-250 Super Duty
2005	Ford F-350 Super Duty
2006-2010	Ford Lobo
