Description: Silv-O-Lite Piston - Chrysler/Dodge 340ci/5.6L (V8)
Description:
Description
Silv-O-Lite Piston - Chrysler/Dodge 340ci/5.6L (V8)
Features & benefits
- Flat top.
- 4 valve reliefs.
- Piston may be used in either left or right cylinder bank.
- Floating pin.
Application summary
| Year | Make / model |
|---|---|
| 1970-1971 | Dodge Challenger |
| 1970-1971 | Dodge Charger |
| 1970-1971 | Dodge Coronet |
| 1968-1971 | Dodge Dart |
| 1968-1971 | Plymouth Barracuda |
| 1971 | Plymouth Belvedere |
| 1970-1971 | Plymouth Cuda |
| 1970-1971 | Plymouth Duster |
| 1968-1971 | Plymouth Satellite |
| 1968-1971 | Plymouth Valiant |
Specifications
- GTIN
- 00800745007018
- Weight
- 16 lb
- Height
- 18 in
- Length
- 4.25 in
- Width
- 9 in
- Life cycle
- Available to Order
- AAM brand code
- SOL
- Warehouse brand code
- BCRJ
- AAIA brand code
- BCRJ
Attributes
- Base Number
- 1267
- Bore (in)
- 4.04
- Bore (mm)
- 102.6
- Bore Diameter
- 4.04
- Compression Ratio
- 10.2
- Crown (cc)
- +10cc
- Crown Type
- FLAT TOP
- Eng. Disp Liters
- 5.6
- Eng. Disp. In.
- 340
- Eng. Disp. Liters
- 5.6
- Engine Family
- Mopar Small Block LA
- Engine Manufacturer
- Chrysler
- Lock
- 98
- Oe Assembly
- 3004516-7
- Oil Ring Thickness
- 0.1875
- Oversize
- .060
- Oversized
- Yes
- Oversizes
- STD .020 .030 .040 .060
- Pin Configuration
- Offset
- Pin Number
- 0984x300B
- Pin Type
- Floating
- Piston Head Type
- Flat
- Piston Material
- Cast 332 Alloy
- Piston Pin Outside Diameter
- .984
- Ring Pack
- 5/64, 5/64, 3/16
- Second Compression Ring Thickness
- 0.0781
- Sold As
- Complete Piston Set
- Top Compression Ring Thickness
- 0.0781
- Top Land
- .310
- Vin Code
- H, J, P
- Year From
- 1968
- Year Range
- 1968-1971
- Year To
- 1971
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1970-1971 Dodge Challenger; 1970-1971 Dodge Charger; 1970-1971 Dodge Coronet; 1968-1971 Dodge Dart; 1968-1971 Plymouth Barracuda; 1971 Plymouth Belvedere; 1970-1971 Plymouth Cuda; 1970-1971 Plymouth Duster; 1968-1971 Plymouth Satellite; 1968-1971 Plymouth Valiant
