RIGID Industries · 920413
Part #: 920413
UPC: 849774030932
Log in for inventory
Notify me when this item is in stock.
pro mess
Description: SR-SERIES 20in. DUAL FUNCTION SAE AUXILARY HIGH BEAM DRIVING LIGHTS
Description:
Description
Off-road auxiliary lighting is one thing, but everyone knows that it is important to have lighting that is also safe and legal for on-road use. RIGID SAE Compliant street legal Fog Lights and Auxiliary High Beam Driving Lights allow them to be used on-the-road and not just off-road. RIGID created the proprietary output spread and height with the new patented optic system. The color temperature of these LEDs was carefully chosen to be a perfect range of pure daylight to penetrate the night for superior clarity on the road. These SAE Compliant lights project long-range high intensity light while drawing very little power and provide up to 50,000 useful hours. Available in many housing sizes, including SR-M, SR-Series single row, E-Series double row and D-Series pods. As an added function, the 20 and 30 in. SR-Series SAE LED light bars offer a bold backlit RIGID branding plate. This feature can be run independently, or in tandem with the forward projecting LEDs. The low-profile optic design, advanced engineered heat sink, durability and the highest quality of strength of a polycarbonate lens is the ultimate solution for your street-legal lighting needs in North America. Own The Night with RIGIDs street legal LED lights.
Features & benefits
- SAE J581 Compliant Street Legal Auxiliary High Beam LED Light
- Impact Resistant Polycarbonate Lens
- High Grade Alloy Housing And Heatsink
- Over/Under Voltage Protection
- IP68 Rated - Dust/Water Ingress
- Pressure Equalizing Vent
- Patented Optics
- White LED Light
- Multi-Function With Rigid Branding Plate
- Integrated Thermal Management System
- 9-36 VDC Operation
- RFI/EMI Protection
Information
Professional Installation Recommended; Street Legal SAE
Specifications
- GTIN
- 00849774030932
- Weight
- 9 lb
- Height
- 6 in
- Length
- 22.85 in
- Width
- 6 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- RIG
- Warehouse brand code
- RIG
- AAIA brand code
- FLWB
Attributes
- A LUX at 10 Meters
- 342.6
- AAM Standard Pack
- 1
- AMP DRAW at 14V DC
- 6.8
- Add-On Part
- 1032 Trucker Hat; 1032 Flat Bill Hat;1037 Tech Flag T-Shirt; 1045 RIGID Logo T-Shirt
- Application
- Automotive
- B Beam Distance with 1 LUX
- 185.1
- Beam Style
- Driving
- Bulb Technology
- LED
- Bulb Type
- LED
- C Beam Distance with .25 LUX
- 370.2
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Field Horizontal
- 68.7
- Field Vertical
- 10.2
- Housing Color
- Black
- Housing Shape
- Rectangular
- LEDs
- 28
- Light Color
- White
- Overall Length
- 20.000 in.
- Peak Beam Intensity (cd)
- 34263
- Peak Beam Intensity cd
- 34263
- Product Weight
- 4.7
- Quantity Sold
- 1
- Raw Lumens
- 8253
- Title
- SR-SERIES 20in DUAL FUNCTION SAE AUXILARY HIGH BEAM DRIVING LIGHTS
- Watts
- 95
Fitment status
This product is universal and will fit your application.
Resources
- Brand logo
- Installation Instructions
- Photo - Out of Package
- Photo - Out of Package
- Photo - Out of Package
- Photo - Out of Package
- Photo - Out of Package
- Photo - Out of Package
- Photo - Lifestyle View
- Photo - Primary
- Photo - Close Up
- Photo - Mounted
- Photo - Mounted
- Regulatory Content Label
- Warranty
- YouTube Video
- Tortured - Rigid Industries
- YouTube Video
- RIGID SAE SR Series Powerful Street Legal Lighting Solution
