Rancho / RS77262
Part #: RS77262
UPC: 039703012072
Loading...
Notify me when this item is in stock.
Description: RS7MT Suspension Shock Absorber; Rancho RS7MT RS77262 Suspension Shock Absorber for Chevrolet Silverado 1500
Description:
Description
Application tuned for precision on-road and off-road handling, Rancho® RS7MT® monotube shocks are highly effective in the dissipation of heat, making them ideal for extreme off-road use and larger wheel and tire packages. RS7MT shocks feature an integrated dirt wiper sealing system that keeps dirt and debris out, hardened piston rod that resists scuffs and corrosion plus an internal rebound bumper to smooth out your ride on any terrain.
Features & benefits
- PRECISE HANDLING AND PERFORMANCE -- Deflective Disc Valving features digressive, linear or progressive tuning based on application requirements for precision handling and performance on- and off-road
- BOLD APPEARANCE -- Black satin finish with distinctive Rancho red logo for an eye-catching look that stands out
- BUY WITH CONFIDENCE -- Comes with Rancho’s Limited Lifetime Warranty
- STRONG AND DURABLE -- Features a 14mm hardened chrome piston rod to resist scuffs & corrosion, double-welded loops at stress areas, double strength closure method and hot form reserve tube
- HANDLES EXTREME TEMPERATURE CHANGES -- Large 2-in. monotube body filled with all-weather fluid allows for cooler operation, increased vehicle control and ability to withstand internal temperatures of -40 to 248°F
- REDUCES FADE -- Full-floating dividing piston and high-pressure nitrogen gas maintains constant pressure against the hydraulic oil, reducing aeration and shock fade
- SMOOTH PERFORMANCE -- Internal rebound bumper and shouldered rubber bushings help reduce noise, vibration and ride harshness while the PTFE-banded piston enhances responsiveness to changing road conditions for an overall smoother ride
- THE RIGHT FIT -- Designed to fit right out of the box, application-specific mounting installs easily with no need for installing sleeves or extra hardware
- KEEPS DIRT AND DEBRIS OUT -- Sealing system with integrated dirt wiper helps keep moisture, dirt and debris from being ingested into the shock and contaminating the oil and destroying the internal seal
- BUILT TO LAST -- Large 46mm fluon-banded piston for consistent sealing between the piston and monotube for precise control, ride and handling; for extra protection, purchase shock boot RS1952 or RS1961
Application summary
| Year | Make / model |
|---|---|
| 2002-2006 | Cadillac Escalade |
| 2003-2006 | Cadillac Escalade ESV |
| 2002-2006 | Cadillac Escalade EXT |
| 2007-2013 | Chevrolet Avalanche |
| 2002-2006 | Chevrolet Avalanche 1500 |
| 2002-2006 | Chevrolet Avalanche 2500 |
| 2002 | Chevrolet C1500 |
| 1999-2006 | Chevrolet Silverado 1500 |
| 2007 | Chevrolet Silverado 1500 Classic |
| 2001-2006 | Chevrolet Silverado 3500 |
| 2007 | Chevrolet Silverado 3500 Classic |
| 2007-2010 | Chevrolet Silverado 3500 HD |
| 2015-2020 | Chevrolet Suburban |
| 2000-2014 | Chevrolet Suburban 1500 |
| 2000-2013 | Chevrolet Suburban 2500 |
| 2016-2019 | Chevrolet Suburban 3500 HD |
| 2000-2020 | Chevrolet Tahoe |
| 1994-2001 | Dodge Ram 1500 |
| 1994-2002 | Dodge Ram 2500 |
| 1999-2006 | GMC Sierra 1500 |
| 2007 | GMC Sierra 1500 Classic |
| 2001-2006 | GMC Sierra 3500 |
| 2007 | GMC Sierra 3500 Classic |
| 2007-2010 | GMC Sierra 3500 HD |
| 2000-2020 | GMC Yukon |
| 2015-2020 | GMC Yukon XL |
| 2000-2014 | GMC Yukon XL 1500 |
| 2000-2013 | GMC Yukon XL 2500 |
Specifications
- GTIN
- 00039703012072
- Weight
- 5.82 lb
- Height
- 3.31 in
- Length
- 24.25 in
- Width
- 3.31 in
- Life cycle
- Available to Order
- AAM brand code
- RAN
- Warehouse brand code
- RAN
- AAIA brand code
- BCKM
Attributes
- Adjustable Damping
- No
- Adjustable Rebound
- No
- Air Adjustable
- No
- Air Ride Suspension
- No
- Bearing Plate Included
- No
- Body Color
- Black
- Body Diameter
- 50
- Body Length
- 375.9
- Body Material
- Steel
- Boot Included
- No
- California Proposition 65
- No
- Coil Over Springs Included
- No
- Color
- Black
- Compressed Bumper Stop
- No
- Compressed Length
- 15.83
- Cylinder Color
- Black
- Cylinder Material
- Steel
- Cylinder Outside Diameter
- 1.97
- Dust Shield Included
- No
- Extended Bumper Stop
- Yes
- Extended Hydraulic Lockout
- No
- Extended Length
- 604
- Finish
- Painted
- Gas Charged
- Yes
- Grade Type
- Performance
- Internal Construction Type
- Single Tube
- Lower Mount Code
- LS47
- Lower Mount Type
- Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL
- Lower Mounting Code
- LS47
- Lower Mounting Description
- Loop Bushing & Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL
- Mounting Hardware Included
- No
- New Or Remanufactured
- New
- Part Description
- Shock Absorber
- Parts Pack
- None
- Parts Pack(s)
- None
- Reserve Tube Diameter
- 2
- Rod Diameter
- 0.5511811023622047
- Shaft Material
- Chromed
- Shock Absorber Body End Measuring Point
- Center of Loop
- Shock Absorber Bore Size
- 1.8110236220472442
- Shock Absorber Rod End Measuring Point
- Center of Loop
- Shock Stroke
- 7.95
- Spring Included
- No
- Spring Isolators Included
- No
- Spring Seat Included
- No
- Travel Length
- 7.95
- Type
- Telescopic
- Upper Mount Code
- LS47
- Upper Mount Type
- Loop Bushing and Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL
- Upper Mounting Code
- LS47
- Upper Mounting Description
- Loop Bushing & Sleeve Mount - 9/16" Sleeve ID X 1.5/8" Sleeve OAL
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
2002-2006 Cadillac Escalade; 2003-2006 Cadillac Escalade ESV; 2002-2006 Cadillac Escalade EXT; 2007-2013 Chevrolet Avalanche; 2002-2006 Chevrolet Avalanche 1500; 2002-2006 Chevrolet Avalanche 2500; 2002 Chevrolet C1500; 1999-2006 Chevrolet Silverado 1500; 2007 Chevrolet Silverado 1500 Classic; 2001-2006 Chevrolet Silverado 3500; 2007 Chevrolet Silverado 3500 Classic; 2007-2010 Chevrolet Silverado 3500 HD; 2015-2020 Chevrolet Suburban; 2000-2014 Chevrolet Suburban 1500; 2000-2013 Chevrolet Suburban 2500; 2016-2019 Chevrolet Suburban 3500 HD; 2000-2020 Chevrolet Tahoe; 1994-2001 Dodge Ram 1500; 1994-2002 Dodge Ram 2500; 1999-2006 GMC Sierra 1500; 2007 GMC Sierra 1500 Classic; 2001-2006 GMC Sierra 3500; 2007 GMC Sierra 3500 Classic; 2007-2010 GMC Sierra 3500 HD; 2000-2020 GMC Yukon; 2015-2020 GMC Yukon XL; 2000-2014 GMC Yukon XL 1500; 2000-2013 GMC Yukon XL 2500
