Race Sport Lighting · H4TLED
Part #: H4TLED
UPC: 817999023428
Log in for inventory
Notify me when this item is in stock.
pro mess
Description: Race Sport Headlight Conversion Kit - 1006565; Terminator Series H4 Fan-less LED Conversion Headlight Kit with Pin Point Projection Optical Aims and Shallow Mount Design
Description:
Description
The TERMINATOR LED Kit is world famous for its superior performance when compared to other LED lights on the marketplace. We use an incredible high performing reflector to focus the light and keep the light forward where it needs to be. This kit boasts just over 2,000LUX per bulb per 4,000LUX per kit in our lab, making it the perfect high output bulb for any vehicle type. Its shallow mount fan-less design keep the bulb from overheating and delivering consistent performance day after day. See 2-3 times further than stock lighting systems, increasing stopping distance by 200 percent. LED technology provides instant on per off light with no ramp-up time. Fanless heat-sink technology. Low mounting depth base design. LED lasts longer than your OEM lighting systems. Focus cup design for narrow projection beam - no glare. Plug-n-play design for easy installation (additional interface harnesses may be required for some vehicles). Allen Key Aim Adjust mechanism. 2 Year Warranty. Rated 2,000 LUX per bulb or 4,000LUX per kit (Raw Lux Measurement @ 1ft is 2,807lx per bulb or 5,614lx per kit). Rated 2,250 Lm per bulb or 4,500 Lm per kit (Raw Lumen Measurement on Lumen meter is 2,374lm per bulb or 4,748lm per kit). Trademark TERMINATOR - 15332-0023 Serial Number 90631817
Application summary
| Year | Make / model |
|---|---|
| 1996-1998 | Acura RL |
| 1995-1998 | Acura TL |
| 1995-1998 | Audi Cabriolet |
| 1976-1990 | Buick LeSabre |
| 1976-1987 | Buick Regal |
| 1975-1985 | Buick Riviera |
| 1975-1988 | Buick Skylark |
| 1985 | Buick Somerset Regal |
| 1975-1986 | Cadillac DeVille |
| 1975-1985 | Cadillac Eldorado |
| 1975-1986 | Cadillac Fleetwood |
| 1976-1985 | Cadillac Seville |
| 1985-2005 | Chevrolet Astro |
| 2004-2012 | Chevrolet Aveo |
| 2006-2011 | Chevrolet Aveo5 |
| 1958-1975 | Chevrolet Bel Air |
| 1981 | Chevrolet Bel Air |
| 1958-1972 | Chevrolet Biscayne |
| 1969-1974 | Chevrolet Blazer |
| 1987-1997 | Chevrolet Blazer |
| 1974-1986 | Chevrolet C10 Suburban |
| 1992-2000 | Chevrolet C1500 |
| 1992-1999 | Chevrolet C1500 Suburban |
| 1974-1986 | Chevrolet C20 Suburban |
| 1992-2000 | Chevrolet C2500 |
| 1992-1999 | Chevrolet C2500 Suburban |
| 1992-2000 | Chevrolet C3500 |
| 1992-2000 | Chevrolet C3500HD |
| 1982-1992 | Chevrolet Camaro |
| 1982-1987 | Chevrolet Cavalier |
| 1958-1982 | Chevrolet Corvette |
| 1984-1996 | Chevrolet Corvette |
| 1959-1960 | Chevrolet El Camino |
| 1964-1987 | Chevrolet El Camino |
| 1996-2014 | Chevrolet Express 1500 |
| 1996-2019 | Chevrolet Express 2500 |
| 1996-2019 | Chevrolet Express 3500 |
| 1964-1974 | Chevrolet G10 Van |
| 1967-1974 | Chevrolet G20 Van |
| 1970-1974 | Chevrolet G30 Van |
| 1958-1985 | Chevrolet Impala |
| 1975-1986 | Chevrolet K10 |
| 1974-1986 | Chevrolet K10 Suburban |
| 1992-1999 | Chevrolet K1500 |
| 1992-1999 | Chevrolet K1500 Suburban |
| 1974-1986 | Chevrolet K20 Suburban |
| 1992-2000 | Chevrolet K2500 |
| 1992-1999 | Chevrolet K2500 Suburban |
| 1977-1985 | Chevrolet K30 |
| 1968-1974 | Chevrolet K30 Pickup |
| 1992-2000 | Chevrolet K3500 |
| 1975-1986 | Chevrolet K5 Blazer |
| 1997-1998 | Chevrolet LUV |
| 1975 | Chevrolet Malibu |
| 1978-1980 | Chevrolet Malibu |
| 1970-1984 | Chevrolet Monte Carlo |
| 1969-1979 | Chevrolet Nova |
| 1998-2002 | Chevrolet Prizm |
| 1987-1988 | Chevrolet R10 Suburban |
| 1989-1991 | Chevrolet R1500 Suburban |
| 1987-1988 | Chevrolet R20 Suburban |
| 1989-1991 | Chevrolet R2500 Suburban |
| 1982-1998 | Chevrolet S10 |
| 1983-1994 | Chevrolet S10 Blazer |
| 1987-1994 | Chevrolet Suburban |
| 1995-1999 | Chevrolet Suburban 1500 |
| 1999-2004 | Chevrolet Tracker |
| 1987-1988 | Chevrolet V10 Suburban |
Specifications
- GTIN
- 00817999023428
- Weight
- 0.65 lb
- Height
- 2.25 in
- Length
- 5.75 in
- Width
- 6.25 in
- Life cycle
- Available to Order
- Alt. part number
- H4TLED
- AAM brand code
- RSP
- Warehouse brand code
- RSP
- AAIA brand code
- GBKR
Attributes
- AAP Selling Package Quantity
- 1
- AAP Selling Package Quantity UOM
- EA
- AAP_UDA_12
- EA
- AAP_UDA_22
- 1
- AAP_UDA_4
- 65
- Add-On
- N/A
- Alternate Part Number
- H4TLED
- Attribute Data
- H4TLED
- Battery Location Info
- N/A
- Beam Pattern
- N/A
- California Proposition 65
- WARNING: Cancer - www.P65Warnings.ca.gov
- Chip Type
- PHILLIPS
- Contain Battery
- No
- Cross-Sell Skus
- RSIKIT,RSUKIT,RS8PRGBW
- Current Draw
- 3.6 Amps
- Estimated Install Time
- 0.5 Hours
- Exportable
- Yes
- Freight Class
- 65
- HAZMAT Item
- No
- IP Rating
- IP67
- Kelvin (Color Temperature)
- 6,000K
- LUX
- 5,614 RAW LUX
- Lead Time AVG
- 1 Day
- Life Expectancy
- 50,000 hours
- Lumens
- 4,748 RAW LUMENS
- Operating Voltage
- 12VDC
- Related Skus
- RSCASH4
- Returnable
- Yes
- Reverse Polarity Protection
- Yes
- SEMA Product Type
- Headlight Conversion Kit
- Shipping Port
- Chicago
- Territory Restrictions
- No
- Title
- Terminator Series H4 Fan-less LED Conversion Headlight Kit with Pin Point Projection Optical Aims and Shallow Mount Design
- Upsell Skus
- H4-G4LED
- Warranty
- 2 year
- Warranty Process
- https://www.racesportinc.com/rma
- Wattage
- 50-Watts
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1996-1998 Acura RL; 1995-1998 Acura TL; 1995-1998 Audi Cabriolet; 1976-1990 Buick LeSabre; 1976-1987 Buick Regal; 1975-1985 Buick Riviera; 1975-1988 Buick Skylark; 1985 Buick Somerset Regal; 1975-1986 Cadillac DeVille; 1975-1985 Cadillac Eldorado; 1975-1986 Cadillac Fleetwood; 1976-1985 Cadillac Seville; 1985-2005 Chevrolet Astro; 2004-2012 Chevrolet Aveo; 2006-2011 Chevrolet Aveo5; 1958-1975 Chevrolet Bel Air; 1981 Chevrolet Bel Air; 1958-1972 Chevrolet Biscayne; 1969-1974 Chevrolet Blazer; 1987-1997 Chevrolet Blazer; 1974-1986 Chevrolet C10 Suburban; 1992-2000 Chevrolet C1500; 1992-1999 Chevrolet C1500 Suburban; 1974-1986 Chevrolet C20 Suburban; 1992-2000 Chevrolet C2500; 1992-1999 Chevrolet C2500 Suburban; 1992-2000 Chevrolet C3500; 1992-2000 Chevrolet C3500HD; 1982-1992 Chevrolet Camaro; 1982-1987 Chevrolet Cavalier; 1958-1982 Chevrolet Corvette; 1984-1996 Chevrolet Corvette; 1959-1960 Chevrolet El Camino; 1964-1987 Chevrolet El Camino; 1996-2014 Chevrolet Express 1500; 1996-2019 Chevrolet Express 2500; 1996-2019 Chevrolet Express 3500; 1964-1974 Chevrolet G10 Van; 1967-1974 Chevrolet G20 Van; 1970-1974 Chevrolet G30 Van; 1958-1985 Chevrolet Impala; 1975-1986 Chevrolet K10; 1974-1986 Chevrolet K10 Suburban; 1992-1999 Chevrolet K1500; 1992-1999 Chevrolet K1500 Suburban; 1974-1986 Chevrolet K20 Suburban; 1992-2000 Chevrolet K2500; 1992-1999 Chevrolet K2500 Suburban; 1977-1985 Chevrolet K30; 1968-1974 Chevrolet K30 Pickup; 1992-2000 Chevrolet K3500; 1975-1986 Chevrolet K5 Blazer; 1997-1998 Chevrolet LUV; 1975 Chevrolet Malibu; 1978-1980 Chevrolet Malibu; 1970-1984 Chevrolet Monte Carlo; 1969-1979 Chevrolet Nova; 1998-2002 Chevrolet Prizm; 1987-1988 Chevrolet R10 Suburban; 1989-1991 Chevrolet R1500 Suburban; 1987-1988 Chevrolet R20 Suburban; 1989-1991 Chevrolet R2500 Suburban; 1982-1998 Chevrolet S10; 1983-1994 Chevrolet S10 Blazer; 1987-1994 Chevrolet Suburban; 1995-1999 Chevrolet Suburban 1500; 1999-2004 Chevrolet Tracker; 1987-1988 Chevrolet V10 Suburban; ...
Resources
- Brand logo
- Datasheet
- Logo Image
- Photo - Out of Package
- Photo - Out of Package
- Photo - Primary
- Photo - Mounted
- Photo - Unmounted
- Warranty
- YouTube Video
- Who is Race Sport?
- First Look - Race Sport Terminator Series LED Light Kit
- The Race Sport Lighting Advantage
- Promo Video - The Leader in Lighting Technology
- Offroad Promo Video
- Truck Week Lighting Promo Video
- Race Sport Lighting Terminator™ LED Headlight Kit
Race Sport Lighting H4TLED
