PROFORM · 69600.1

View More

Part #: 69600.1
UPC: 037995960019

Loading availability... Log in for inventory

Notify me when this item is in stock.

Brand: PROFORM Series: Slim-Fit Radiator Systems

Description: No description available.

Cancer and Reproductive Harm - www.P65Warnings.ca.gov

Description

No description available.

Application summary

Year	Make / model
1967-1969	Chevrolet Camaro
1967-1969	Pontiac Firebird

Specifications

GTIN: 00037995960019
Weight: 28.5 lb
Height: 22.3 in
Length: 31.5 in
Width: 7.8 in
EO: Legal US
Life cycle: Available to Order
AAM brand code: PRF
Warehouse brand code: PRF
AAIA brand code: BCHW

Attributes

Blade Color:: Black
Blade Material: Plastic
Blade Material:: Plastic
California Proposition 65: WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
Cap Color: Silver
Cap Included: Yes
Category: Radiators
Color: Silver
Condition: NEW
Consumer Features and Benefits: Wiring harness and radiator cap
Consumer Marketing Description: Tight spaces are no longer the enemy. Engineered by the experts at PROFORM, these slim-fit radiator systems boast a total thickness of less than 4”--making them up to 40% thinner than similar aftermarket products. With an integrated design including radiator, shroud, and fan, these slim-fit systems are defined by sleek angles, eye-catching perforations, and an exclusive slant-edge cap, meaning they do not sacrifice under-hood style in the pursuit of cooling performance. Say goodbye to cobbled-together cooling paraphernalia: these all-in-one radiator systems arrive ready for a direct fit into your compatible application.
Core Height: 17.00
Core Height (in): 17
Core Height (in.): 17.00 in.
Core Height (in.):: 17.00 in.
Core Thickness: 2.40
Core Thickness (in): 2.4
Core Thickness (in.): 2.400
Core Thickness (in.):: 2.400
Core Width: 23.00
Core Width (in): 23
Core Width (in.): 23.000
Core Width (in.):: 23.000
Down Flow Or Cross Flow Type: Cross Flow
Drain Plug Included: Yes
Engine Oil Cooler Fittings Distance Apart: 26.475
Fan CFM: 2100
Fan CFM Range: 2,100-2,199
Fan CFM Range:: 2,100-2,199
Fan Diameter (in.): 16.00 in.
Fan Diameter (in.):: 16.00 in.
Fan Included: Yes
Fan Included:: Yes
Fan Quantity: Single
Fan Quantity:: Single
Feature/Benefit: Billet aluminum filler neck with high capacity overflow tube
Finish: Natural
Height (IN): 18.5
Inlet Diameter (in): 1.5
Inlet Location: Driver Side
Inlet Location:: Upper left
Make: Pontiac
Max Recommended Horsepower: 600
Maximum Fan CFM: 2,100 cfm
Maximum Fan CFM:: 2,100 cfm
Mounting Style: Direct Fit
Notes: Total thickness of radiator, fan and shroud is less than 4.00 in. Includes adjustable fan thermostat.
Notes:: Total thickness of radiator, fan and shroud is less than 4.00 in. Includes adjustable fan thermostat.
Number Of Blades: 8
Outlet Diameter (in): 1.75
Outlet Location: Passenger Side
Outlet Location:: Lower right
Overall Height (in.): 18.500
Overall Height (in.):: 18.500
Overall Thickness (in.): 4.00
Overall Thickness (in.):: 4.00
Overall Width (in): 28.1
Overall Width (in.): 28.100
Overall Width (in.):: 28.100
Part Type: Radiator
Product Line: Proform Slim-Fit Radiator Systems
Product Line:: Proform Slim-Fit Radiator Systems
Quantity: Sold as a kit.
Quantity:: Sold as a kit.
Radiator Cap Included: Yes
Radiator Cap Included:: Yes
Radiator Finish: Natural
Radiator Finish:: Natural
Radiator Inlet Size: 1.500
Radiator Inlet Size:: 1.500
Radiator Material: Aluminum
Radiator Material:: Aluminum
Radiator Outlet Size: 1.750
Radiator Outlet Size:: 1.750
Radiator Style: Crossflow
Radiator Style:: Crossflow
Row Quantity: 2
Row Quantity:: 2
Series: Slim-Fit
Shroud Color: Natural
Shroud Color:: Natural
Shroud Material: Aluminum
Shroud Material:: Aluminum
Tank Material: Aluminum
Title: Slim-Fit Radiator System 67-69 Camaro; Manual
Tool Type: Piston Installation Tools
Trans Cooler Adapter Fittings Included: No
Trans Cooler Adapter Fittings Included:: No
Transmission Cooler: No
Transmission Cooler:: No
Transmission Type: Manual
Tube Size: 1
Tube Size:: 1
Voltage Compatibility: 12
