Oracle Lighting · 1710-001
Part #: 1710-001
UPC: 171000120118
Log in for inventory
Notify me when this item is in stock.
pro mess
Description: Single Channel In-Line LED Controller; In-Line controller directly wires up in between a power source and the LED product. Contains multiple levels of controls and functions for flex strips.
Description:
Description
Easy to install LED controller from ORACLE Lighting. Called "in-line" because it directly wires up in between a power source and the LED product. Modes include: - Breathing Mode - Heartbeat Mode - Primary and Secondary Strobe Modes - Control Dimming Mode Product Details: - Input: 8-16V DC - Max load current: 12 Amps - Output: 1 channel - Output Power: 144 Watts - Dynamic Modes: 5 - Levels of Control: 256 - Levels of Speed: 6 - Levels of Brightness: 8 Also included: - Speed Variable Button - Visible markings for the + and - 12V and LED sources.
Features & benefits
- Modes include: Breathing Mode, Heartbeat Mode, Primary and Secondary Strobe Modes, Control Dimming Mode
Specifications
- GTIN
- 00171000120118
- Weight
- 1 lb
- Height
- 9 in
- Length
- 4 in
- Width
- 9 in
- Life cycle
- Available to Order
- AAM brand code
- ORL
- Warehouse brand code
- FQCV
- AAIA brand code
- FQCV
Attributes
- Add-On
- N/A
- California Proposition 65
- WARNING: Cancer - www.P65Warnings.ca.gov
- Color
- White
- Gender
- Male
- Length
- 4
- Max load current
- 12 Amps
- Outputs
- 1 channel
- Terminal Gender
- Male
- Terminal Material
- N/A
- Terminal Quantity
- 2
- Terminal Type
- Lead Wire
- Title
- 1710-001 - ORACLE Single Channel In-Line LED Controller
- Voltage
- 8 16V DC
- Wattage
- 144 Watts
- Wire Gauge Measurement
- 20
- Wire Quantity
- 4
- Wiring Harness Included
- Yes
Fitment status
This product is universal and will fit your application.
