Motive Gear · G885488
Part #: G885488
UPC: 698231021996
Log in for inventory
Notify me when this item is in stock.
Description: Precision Differential Ring and Pinion maintains correct power distribution to a; This Differential Ring and Pinion is precision manufactured to OEM gear ratios and tooth geometry. It distributes torque efficiently between axles, maximizing traction and minimizing wear in commercial trucks.
Description:
Description
Motive Gear offers some of the toughest drive train components on the market today. If you are looking for the largest line of performance ring and pinion gear options available with gear sets in a wide range of ratios for nearly every application, both on and off-road, check out Motive Gear. Motive Gear products can be found in the winner's circle at racing events worldwide. The superior quality of Motive Gear components is the result of years of racing development, outstanding design and state-of-the-art manufacturing methods. Extensive testing is performed on all products by our in-house engineers.
Features & benefits
- Designed for compatibility with OEM-specified gear oil viscosities, ensuring correct lubrication under all operating conditions.
- Heat-treated alloy steel construction withstands peak torque demands of loaded commercial trucks, preventing gear tooth fatigue and breakage.
- OEM-spec gear ratios preserve intended vehicle speed, performance, and fuel economy characteristics.
- Precision fits to carrier housing bores eliminate shimming uncertainty and simplify installation for experienced drivetrain technicians.
- Precision-machined gears and tight backlash tolerances ensure smooth power transfer and efficient torque distribution between axles.
Information
RP GM 8.5" 8.6" 4.88 MGP
Application summary
| Year | Make / model |
|---|---|
| 1973-1975 | Buick Apollo |
| 1971-1989 | Buick Electra |
| 2004-2007 | Buick Rainier |
| 1976-1987 | Buick Regal |
| 1975-1978 | Buick Riviera |
| 1970-1972 | Buick Skylark |
| 1975-1979 | Buick Skylark |
| 1970-1972 | Buick Sportwagon |
| 1999-2000 | Cadillac Escalade |
| 2002-2013 | Cadillac Escalade |
| 2003-2013 | Cadillac Escalade ESV |
| 2002-2013 | Cadillac Escalade EXT |
| 2007-2013 | Chevrolet Avalanche |
| 2002-2006 | Chevrolet Avalanche 1500 |
| 1970-1975 | Chevrolet Bel Air |
| 1987-1994 | Chevrolet Blazer |
| 1979-1986 | Chevrolet C10 |
| 1988-1999 | Chevrolet C1500 |
| 1989-2000 | Chevrolet C2500 |
| 1970-1981 | Chevrolet Camaro |
| 1970-1996 | Chevrolet Caprice |
| 1973 | Chevrolet Chevelle |
| 2004-2013 | Chevrolet Colorado |
| 1991-1994 | Chevrolet Commercial Chassis |
| 1971-1976 | Chevrolet El Camino |
| 1970 | Chevrolet Estate |
| 1996-2014 | Chevrolet Express 1500 |
| 1996-1998 | Chevrolet Express 2500 |
| 1979-1995 | Chevrolet G10 |
| 1975-1995 | Chevrolet G20 |
| 1971-1985 | Chevrolet Impala |
| 1994-1996 | Chevrolet Impala |
| 1977-1986 | Chevrolet K10 |
| 1988-1999 | Chevrolet K1500 |
| 1977-1986 | Chevrolet K20 |
| 1988-1991 | Chevrolet K2500 |
| 1977-1986 | Chevrolet K5 Blazer |
| 1971-1972 | Chevrolet Kingswood |
| 1978-1983 | Chevrolet Malibu |
| 1973-1978 | Chevrolet Monte Carlo |
| 1970-1979 | Chevrolet Nova |
| 1994-2004 | Chevrolet S10 |
| 1994 | Chevrolet S10 Blazer |
| 1999-2017 | Chevrolet Silverado 1500 |
| 2007 | Chevrolet Silverado 1500 Classic |
| 2007 | Chevrolet Silverado 1500 HD Classic |
| 2003-2006 | Chevrolet SSR |
| 1987 | Chevrolet Suburban |
| 1990-1994 | Chevrolet Suburban |
| 1995-2013 | Chevrolet Suburban 1500 |
| 1995-2017 | Chevrolet Tahoe |
| 1971-1972 | Chevrolet Townsman |
| 2002-2009 | Chevrolet Trailblazer |
| 2002-2006 | Chevrolet Trailblazer EXT |
| 1977-1978 | GMC C15 Suburban |
| 1979-1986 | GMC C1500 |
| 1988-1998 | GMC C1500 |
| 1979-1986 | GMC C1500 Suburban |
| 1992-1999 | GMC C1500 Suburban |
| 1977-1978 | GMC C25 Suburban |
| 1997-1998 | GMC C2500 |
| 1979-1986 | GMC C2500 Suburban |
| 2004-2012 | GMC Canyon |
| 2002-2009 | GMC Envoy |
| 2002-2006 | GMC Envoy XL |
| 2004-2005 | GMC Envoy XUV |
| 1979-1995 | GMC G1500 |
| 1978 | GMC G25 |
| 1979-1995 | GMC G2500 |
| 1994 | GMC Jimmy |
| 1977-1978 | GMC K15 |
| 1977-1978 | GMC K15 Suburban |
Specifications
- GTIN
- 00698231021996
- Weight
- 19 lb
- Height
- 5.25 in
- Length
- 15 in
- Width
- 11 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- MOT
- Warehouse brand code
- MOT
- AAIA brand code
- BHHD
Attributes
- App/Model
- GM 8.625"
- Axle Type
- GM 8.5 in.
- California Proposition 65
- WARNING: Cancer - www.P65Warnings.ca.gov
- Cover Bolt Quantity
- 10
- Differential Carrier Break
- 2.73 Ratio and Higher
- Differential Case Design Type
- GM 8.5
- Gear Ratio
- 4.88
- Mounting Location
- Rear
- Pinion Gear Tooth Quantity
- 8
- Pinion Shaft Diameter
- 1.626
- Pinion Spline Count
- 30
- Position
- Rear
- Ratio
- 4.88
- Ring Gear Bolt Quantity
- 10
- Ring Gear Diameter
- 8.5
- Ring Gear Material
- 8620 Steel
- Ring Gear Outside Diameter
- 8.5
- Ring Gear Rotation
- Standard
- Ring Gear Tooth Quantity
- 39
- Ring and Pinion Gear Ratio
- 4.88
- Taxonomy
- GM 8.5/GM 8.625
- Taxonomy A
- LD Differential
- Taxonomy B
- Ring and Pinions
- Taxonomy C
- Rear
- Taxonomy D
- 4.88
- Title
- Differential Ring and Pinion
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1973-1975 Buick Apollo; 1971-1989 Buick Electra; 2004-2007 Buick Rainier; 1976-1987 Buick Regal; 1975-1978 Buick Riviera; 1970-1972 Buick Skylark; 1975-1979 Buick Skylark; 1970-1972 Buick Sportwagon; 1999-2000 Cadillac Escalade; 2002-2013 Cadillac Escalade; 2003-2013 Cadillac Escalade ESV; 2002-2013 Cadillac Escalade EXT; 2007-2013 Chevrolet Avalanche; 2002-2006 Chevrolet Avalanche 1500; 1970-1975 Chevrolet Bel Air; 1987-1994 Chevrolet Blazer; 1979-1986 Chevrolet C10; 1988-1999 Chevrolet C1500; 1989-2000 Chevrolet C2500; 1970-1981 Chevrolet Camaro; 1970-1996 Chevrolet Caprice; 1973 Chevrolet Chevelle; 2004-2013 Chevrolet Colorado; 1991-1994 Chevrolet Commercial Chassis; 1971-1976 Chevrolet El Camino; 1970 Chevrolet Estate; 1996-2014 Chevrolet Express 1500; 1996-1998 Chevrolet Express 2500; 1979-1995 Chevrolet G10; 1975-1995 Chevrolet G20; 1971-1985 Chevrolet Impala; 1994-1996 Chevrolet Impala; 1977-1986 Chevrolet K10; 1988-1999 Chevrolet K1500; 1977-1986 Chevrolet K20; 1988-1991 Chevrolet K2500; 1977-1986 Chevrolet K5 Blazer; 1971-1972 Chevrolet Kingswood; 1978-1983 Chevrolet Malibu; 1973-1978 Chevrolet Monte Carlo; 1970-1979 Chevrolet Nova; 1994-2004 Chevrolet S10; 1994 Chevrolet S10 Blazer; 1999-2017 Chevrolet Silverado 1500; 2007 Chevrolet Silverado 1500 Classic; 2007 Chevrolet Silverado 1500 HD Classic; 2003-2006 Chevrolet SSR; 1987 Chevrolet Suburban; 1990-1994 Chevrolet Suburban; 1995-2013 Chevrolet Suburban 1500; 1995-2017 Chevrolet Tahoe; 1971-1972 Chevrolet Townsman; 2002-2009 Chevrolet Trailblazer; 2002-2006 Chevrolet Trailblazer EXT; 1977-1978 GMC C15 Suburban; 1979-1986 GMC C1500; 1988-1998 GMC C1500; 1979-1986 GMC C1500 Suburban; 1992-1999 GMC C1500 Suburban; 1977-1978 GMC C25 Suburban; 1997-1998 GMC C2500; 1979-1986 GMC C2500 Suburban; 2004-2012 GMC Canyon; 2002-2009 GMC Envoy; 2002-2006 GMC Envoy XL; 2004-2005 GMC Envoy XUV; 1979-1995 GMC G1500; 1978 GMC G25; 1979-1995 GMC G2500; 1994 GMC Jimmy; 1977-1978 GMC K15; 1977-1978 GMC K15 Suburban; ...
