Motive Gear · D60-373
Part #: D60-373
UPC: 698231357927
Loading...
Notify me when this item is in stock.
Description: Precision Differential Ring and Pinion maintains correct power distribution to a; This Differential Ring and Pinion is precision manufactured to OEM gear ratios and tooth geometry. It distributes torque efficiently between axles, maximizing traction and minimizing wear in commercial trucks.
Description:
Description
Motive Gear offers some of the toughest drive train components on the market today. If you are looking for the largest line of performance ring and pinion gear options available with gear sets in a wide range of ratios for nearly every application, both on and off-road, check out Motive Gear. Motive Gear products can be found in the winner's circle at racing events worldwide. The superior quality of Motive Gear components is the result of years of racing development, outstanding design and state-of-the-art manufacturing methods. Extensive testing is performed on all products by our in-house engineers.
Features & benefits
- Designed for compatibility with OEM-specified gear oil viscosities, ensuring correct lubrication under all operating conditions.
- Heat-treated alloy steel construction withstands peak torque demands of loaded commercial trucks, preventing gear tooth fatigue and breakage.
- OEM-spec gear ratios preserve intended vehicle speed, performance, and fuel economy characteristics.
- Precision fits to carrier housing bores eliminate shimming uncertainty and simplify installation for experienced drivetrain technicians.
- Precision-machined gears and tight backlash tolerances ensure smooth power transfer and efficient torque distribution between axles.
Information
RP DANA 60 3.73 STANDARD MG
Application summary
| Year | Make / model |
|---|---|
| 1967 | Chevrolet C10 Panel |
| 1967-1972 | Chevrolet C10 Pickup |
| 1967 | Chevrolet C20 Panel |
| 1965-1972 | Chevrolet C20 Pickup |
| 2003-2009 | Chevrolet Express 2500 |
| 1968-1972 | Chevrolet G10 Van |
| 1979-1987 | Chevrolet G30 |
| 1967-1972 | Chevrolet K10 Pickup |
| 1967-1972 | Chevrolet K10 Suburban |
| 1977-1986 | Chevrolet K30 |
| 1988-1991 | Chevrolet K3500 |
| 1988 | Chevrolet V30 |
| 1975-1980 | Dodge B100 |
| 1971-1974 | Dodge B100 Van |
| 1975-1980 | Dodge B200 |
| 1971-1974 | Dodge B200 Van |
| 1981-1994 | Dodge B250 |
| 1995-1998 | Dodge B2500 |
| 1975-1980 | Dodge B300 |
| 1971-1974 | Dodge B300 Van |
| 1981-1994 | Dodge B350 |
| 1995-1998 | Dodge B3500 |
| 1966-1974 | Dodge Charger |
| 1975-1980 | Dodge D200 |
| 1968-1974 | Dodge D200 Pickup |
| 1960-1967 | Dodge D200 Series |
| 1981-1993 | Dodge D250 |
| 1975-1980 | Dodge D300 |
| 1968-1974 | Dodge D300 Pickup |
| 1960-1967 | Dodge D300 Series |
| 1981-1993 | Dodge D350 |
| 1968-1976 | Dodge Dart |
| 2004-2006 | Dodge Ram 1500 |
| 1994-2002 | Dodge Ram 2500 |
| 1999-2003 | Dodge Ram 2500 Van |
| 1994-2002 | Dodge Ram 3500 |
| 1999-2003 | Dodge Ram 3500 Van |
| 1975-1980 | Dodge W200 |
| 1968-1974 | Dodge W200 Pickup |
| 1963-1967 | Dodge W200 Series |
| 1981-1993 | Dodge W250 |
| 1975-1980 | Dodge W300 |
| 1968-1974 | Dodge W300 Pickup |
| 1960-1967 | Dodge W300 Series |
| 1981-1993 | Dodge W350 |
| 1971-1972 | Fargo B200 Van |
| 1971-1972 | Fargo B300 Van |
| 1966-1967 | Fargo D200 Panel Delivery |
| 1966-1972 | Fargo D200 Pickup |
| 1966-1972 | Fargo W200 Pickup |
| 2007-2014 | Ford E-150 |
| 1992-1996 | Ford E-150 Econoline |
| 1992-1996 | Ford E-150 Econoline Club Wagon |
| 1969-1974 | Ford E-200 Econoline |
| 2003-2014 | Ford E-250 |
| 1979-2002 | Ford E-250 Econoline |
| 1979-1991 | Ford E-250 Econoline Club Wagon |
| 1969-1974 | Ford E-300 Econoline |
| 2002-2005 | Ford E-350 Club Wagon |
| 1975-2000 | Ford E-350 Econoline |
| 1977-2002 | Ford E-350 Econoline Club Wagon |
| 1999-2019 | Ford E-350 Super Duty |
| 2000-2002 | Ford E-450 Econoline Super Duty |
| 2003-2008 | Ford E-450 Super Duty |
| 1996 | Ford Econoline Super Duty |
| 1965-1971 | Ford F-100 |
| 1954-1986 | Ford F-250 |
| 1975-1978 | Ford F-350 |
| 1980-1981 | Ford F-350 |
| 1984 | Ford F-350 |
| 1967-1972 | GMC C15/C1500 Pickup |
| 1968-1972 | GMC C15/C1500 Suburban |
Specifications
- GTIN
- 00698231357927
- Weight
- 17.3 lb
- Height
- 5.25 in
- Length
- 15 in
- Width
- 11 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- MOT
- Warehouse brand code
- MOT
- AAIA brand code
- BHHD
Attributes
- App/Model
- Dana 60 Standard
- Axle Type
- Dana 60
- California Proposition 65
- WARNING: Cancer - www.P65Warnings.ca.gov
- Cover Bolt Quantity
- 10
- Differential Carrier Break
- 4.10 Ratio and Lower
- Differential Case Design Type
- Dana 60 Standard
- Gear Ratio
- 3.73
- Mounting Location
- Rear
- Pinion Gear Tooth Quantity
- 11
- Pinion Shaft Diameter
- 1.626
- Pinion Spline Count
- 29
- Position
- Rear
- Ratio
- 3.73
- Ring Gear Bolt Quantity
- 12
- Ring Gear Diameter
- 9.75
- Ring Gear Material
- 8620 Steel
- Ring Gear Outside Diameter
- 9.75
- Ring Gear Rotation
- Standard
- Ring Gear Tooth Quantity
- 41
- Ring and Pinion Gear Ratio
- 3.73
- Taxonomy
- Dana 60
- Taxonomy A
- LD Differential
- Taxonomy B
- Ring and Pinions
- Taxonomy C
- Rear
- Taxonomy D
- 3.73
- Title
- Differential Ring and Pinion
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1967 Chevrolet C10 Panel; 1967-1972 Chevrolet C10 Pickup; 1967 Chevrolet C20 Panel; 1965-1972 Chevrolet C20 Pickup; 2003-2009 Chevrolet Express 2500; 1968-1972 Chevrolet G10 Van; 1979-1987 Chevrolet G30; 1967-1972 Chevrolet K10 Pickup; 1967-1972 Chevrolet K10 Suburban; 1977-1986 Chevrolet K30; 1988-1991 Chevrolet K3500; 1988 Chevrolet V30; 1975-1980 Dodge B100; 1971-1974 Dodge B100 Van; 1975-1980 Dodge B200; 1971-1974 Dodge B200 Van; 1981-1994 Dodge B250; 1995-1998 Dodge B2500; 1975-1980 Dodge B300; 1971-1974 Dodge B300 Van; 1981-1994 Dodge B350; 1995-1998 Dodge B3500; 1966-1974 Dodge Charger; 1975-1980 Dodge D200; 1968-1974 Dodge D200 Pickup; 1960-1967 Dodge D200 Series; 1981-1993 Dodge D250; 1975-1980 Dodge D300; 1968-1974 Dodge D300 Pickup; 1960-1967 Dodge D300 Series; 1981-1993 Dodge D350; 1968-1976 Dodge Dart; 2004-2006 Dodge Ram 1500; 1994-2002 Dodge Ram 2500; 1999-2003 Dodge Ram 2500 Van; 1994-2002 Dodge Ram 3500; 1999-2003 Dodge Ram 3500 Van; 1975-1980 Dodge W200; 1968-1974 Dodge W200 Pickup; 1963-1967 Dodge W200 Series; 1981-1993 Dodge W250; 1975-1980 Dodge W300; 1968-1974 Dodge W300 Pickup; 1960-1967 Dodge W300 Series; 1981-1993 Dodge W350; 1971-1972 Fargo B200 Van; 1971-1972 Fargo B300 Van; 1966-1967 Fargo D200 Panel Delivery; 1966-1972 Fargo D200 Pickup; 1966-1972 Fargo W200 Pickup; 2007-2014 Ford E-150; 1992-1996 Ford E-150 Econoline; 1992-1996 Ford E-150 Econoline Club Wagon; 1969-1974 Ford E-200 Econoline; 2003-2014 Ford E-250; 1979-2002 Ford E-250 Econoline; 1979-1991 Ford E-250 Econoline Club Wagon; 1969-1974 Ford E-300 Econoline; 2002-2005 Ford E-350 Club Wagon; 1975-2000 Ford E-350 Econoline; 1977-2002 Ford E-350 Econoline Club Wagon; 1999-2019 Ford E-350 Super Duty; 2000-2002 Ford E-450 Econoline Super Duty; 2003-2008 Ford E-450 Super Duty; 1996 Ford Econoline Super Duty; 1965-1971 Ford F-100; 1954-1986 Ford F-250; 1975-1978 Ford F-350; 1980-1981 Ford F-350; 1984 Ford F-350; 1967-1972 GMC C15/C1500 Pickup; 1968-1972 GMC C15/C1500 Suburban; ...
