Melling Engine Parts / Melling Tool Co. · M396
Part #: M396
UPC: 729295105169
Log in for inventory
Notify me when this item is in stock.
Description: Stock Replacement Oil Pump; M396 Stock Replacement : Standard Volume, Standard Pressure, Cast Aluminum Oil Pump With Gasket
Description:
Description
Made in USA. Melling oil pumps provide dependable performance every time in every application. Every Melling oil pump is engineered and assembled to the highest production standards from high quality materials. All Melling oil pumps use the latest in gear and gerotor technology to provide the highest level of quality and performance. Gears are machined to close tolerances to ensure proper engine pressure and correct, efficient pump operation. End plates are precision ground for maximum wear resistance. Every Melling oil pump is individually tested for pressure and flow under conditions designed to duplicate actual engine operating conditions.
Features & benefits
- Manufactured from high quality materials for consistent durable wear
- Melling oil pumps are tested for pressure and flow under operating conditions to ensure quality
- Designed for long-life and worry-free performance
- Precision engineered for optimum fit and function
Application summary
| Year | Make / model |
|---|---|
| 2015-2017 | Ford F-150 |
| 2011-2017 | Ford Mustang |
Specifications
- GTIN
- 00729295105169
- Weight
- 3.2 lb
- Height
- 2.5 in
- Length
- 8.25 in
- Width
- 6 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- MEL
- Warehouse brand code
- BCBC
- AAIA brand code
- BCBC
Attributes
- Bolts Included
- No
- Bushing Included
- No
- California Proposition 65
- No
- Cotter Pin Included
- No
- Cover Material
- Aluminum
- Drive Shaft Included
- No
- Drive Type
- Crankshaft
- Finish
- Rust Preventative
- Gasket Or Seal Included
- Yes
- Gears Included
- Not Applicable
- Governor Spinner Included
- No
- Grade Type
- Standard Replacement
- Guide Included
- No
- Height
- 7.0
- Housing Material
- Cast Aluminum
- Inlet Size (in)
- 1.000
- Inlet Size (mm)
- 25.00
- Intermediate Shaft Included
- No
- Mounting Hole Diameter
- 0.375
- Mounting Hole Quantity
- 4
- Nylon Bushing Included
- No
- O-Ring Included
- No
- Oil Pump Type
- Rotary
- Pick Up Tube Diameter
- 1.0
- Pickup Screen Included
- No
- Pump Cover Included
- Yes
- Rotor Material
- Powdered Metal
- Shaft Material
- Not Applicable
- Spacer Included
- No
- Timing Cover Included
- No
- Title
- Engine Oil Pump
- Washers Included
- No
- Width
- 7.75
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
2015-2017 Ford F-150; 2011-2017 Ford Mustang
