Melling Engine Parts / Melling Tool Co. · M340
Part #: M340
UPC: 729295103639
Loading...
Notify me when this item is in stock.
Description: Stock Replacement Oil Pump; M340 Stock Replacement : Standard Volume, Standard Pressure, Cast Aluminum Oil Pump With Gasket
Description:
Description
Made in USA. Melling oil pumps provide dependable performance every time in every application. Every Melling oil pump is engineered and assembled to the highest production standards from high quality materials. All Melling oil pumps use the latest in gear and gerotor technology to provide the highest level of quality and performance. Gears are machined to close tolerances to ensure proper engine pressure and correct, efficient pump operation. End plates are precision ground for maximum wear resistance. Every Melling oil pump is individually tested for pressure and flow under conditions designed to duplicate actual engine operating conditions.
Features & benefits
- Precision engineered for optimum fit and function
- Manufactured from high quality materials for consistent durable wear
- Designed for long-life and worry-free performance
- Meets or exceeds original equipment specifications
Application summary
| Year | Make / model |
|---|---|
| 2007 | Ford E-450 Super Duty |
| 2005-2014 | Ford Expedition |
| 2006-2010 | Ford Explorer |
| 2007-2010 | Ford Explorer Sport Trac |
| 2004-2010 | Ford F-150 |
| 2004 | Ford F-150 Heritage |
| 2004-2010 | Ford F-250 Super Duty |
| 2004-2010 | Ford F-350 Super Duty |
| 2006-2008 | Ford Lobo |
| 2005-2010 | Ford Mustang |
| 2006-2008 | Lincoln Mark LT |
| 2005-2014 | Lincoln Navigator |
| 2006-2010 | Mercury Mountaineer |
Specifications
- GTIN
- 00729295103639
- Weight
- 3.4 lb
- Height
- 2.5 in
- Length
- 8.25 in
- Width
- 6 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- MEL
- Warehouse brand code
- BCBC
- AAIA brand code
- BCBC
Attributes
- Bolts Included
- No
- Bushing Included
- No
- California Proposition 65
- No
- Cotter Pin Included
- No
- Cover Material
- Aluminum
- Drive Shaft Included
- No
- Drive Type
- Crankshaft
- Finish
- Rust Preventative
- Gasket Or Seal Included
- Yes
- Gears Included
- Not Applicable
- Governor Spinner Included
- No
- Grade Type
- Standard Replacement
- Guide Included
- No
- Height
- 6.18
- Housing Material
- Cast Aluminum
- Inlet Size (in)
- 1.000
- Inlet Size (mm)
- 25.40
- Intermediate Shaft Included
- No
- Mounting Hole Diameter
- 0.25
- Mounting Hole Quantity
- 4
- Nylon Bushing Included
- No
- O-Ring Included
- Yes
- Oil Pump Type
- Rotary
- Pick Up Screen Diameter
- 0.938
- Pick Up Tube Diameter
- 1.000
- Pickup Screen Included
- No
- Pump Cover Included
- Yes
- Rotor Material
- Powdered Metal
- Shaft Material
- Not Applicable
- Spacer Included
- No
- Timing Cover Included
- No
- Title
- Engine Oil Pump
- Washers Included
- No
- Width
- 8.0
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
2007 Ford E-450 Super Duty; 2005-2014 Ford Expedition; 2006-2010 Ford Explorer; 2007-2010 Ford Explorer Sport Trac; 2004-2010 Ford F-150; 2004 Ford F-150 Heritage; 2004-2010 Ford F-250 Super Duty; 2004-2010 Ford F-350 Super Duty; 2006-2008 Ford Lobo; 2005-2010 Ford Mustang; 2006-2008 Lincoln Mark LT; 2005-2014 Lincoln Navigator; 2006-2010 Mercury Mountaineer
