Melling Engine Parts / Melling Tool Co. / M152
Part #: M152
UPC: 729295102496
Loading...
Notify me when this item is in stock.
Description: Stock Replacement Oil Pump; M152 Stock Replacement : Standard Volume, Standard Pressure, Cast Iron Oil Pump With Gasket
Description:
This part number superseded M111.
Description
Made in USA. Melling oil pumps provide dependable performance every time in every application. Every Melling oil pump is engineered and assembled to the highest production standards from high quality materials. All Melling oil pumps use the latest in gear and gerotor technology to provide the highest level of quality and performance. Gears are machined to close tolerances to ensure proper engine pressure and correct, efficient pump operation. End plates are precision ground for maximum wear resistance. Every Melling oil pump is individually tested for pressure and flow under conditions designed to duplicate actual engine operating conditions.
Features & benefits
- Precision engineered for optimum fit and function
- Manufactured from high quality materials for consistent durable wear
- Designed for long-life and worry-free performance
- Meets or exceeds original equipment specifications
Application summary
| Year | Make / model |
|---|---|
| 1989-1990 | Nissan 240SX |
| 1981-1983 | Nissan 280ZX |
| 1986-1994 | Nissan D21 |
| 1998-2004 | Nissan Frontier |
| 1987 | Nissan Pathfinder |
| 1995-2004 | Nissan Pickup |
| 1987-1988 | Nissan Van |
| 2000-2004 | Nissan Xterra |
Specifications
- GTIN
- 00729295102496
- Weight
- 4.02 lb
- Height
- 4.75 in
- Length
- 6 in
- Width
- 5.75 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- MEL
- Warehouse brand code
- BCBC
- AAIA brand code
- BCBC
Attributes
- Bolts Included
- No
- Bushing Included
- No
- California Proposition 65
- No
- Cotter Pin Included
- No
- Cover Material
- Cast Iron
- Drive Shaft Included
- No
- Drive Type
- Drive Shaft
- Finish
- Rust Preventative
- Gasket Or Seal Included
- Yes
- Gear Material
- Steel
- Gears Included
- Yes
- Governor Spinner Included
- No
- Grade Type
- Standard Replacement
- Guide Included
- No
- Height
- 6.05
- Housing Material
- Cast Iron
- Inlet Size (in)
- 0.594
- Inlet Size (mm)
- 15.09
- Intermediate Shaft Included
- No
- Mounting Hole Diameter
- 0.375
- Mounting Hole Quantity
- 4
- Nylon Bushing Included
- No
- O-Ring Included
- No
- Oil Pump Type
- Gear
- Pick Up Tube Diameter
- 0.594
- Pickup Screen Included
- No
- Pump Cover Included
- Yes
- Shaft Material
- Not Applicable
- Spacer Included
- No
- Timing Cover Included
- No
- Title
- Engine Oil Pump
- Washers Included
- No
- Width
- 2.76
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1989-1990 Nissan 240SX; 1981-1983 Nissan 280ZX; 1986-1994 Nissan D21; 1998-2004 Nissan Frontier; 1987 Nissan Pathfinder; 1995-2004 Nissan Pickup; 1987-1988 Nissan Van; 2000-2004 Nissan Xterra
