Melling Engine Parts / Melling Tool Co. / M-77HV-353SW
Part #: M-77HV-353SW
UPC: 729295103974
Loading...
Notify me when this item is in stock.
Description: High Volume Replacement Oil Pump; M-77HV-353SW Stock Replacement : High Volume, Standard Pressure, Cast Iron Oil Pump
Description:
Description
Made in USA. Melling high volume oil pumps increase the amount of oil flow by an average of 20% through the engine improving oil pressure at idle providing dependable performance every time in every application. Every Melling high volume oil pump is engineered and assembled to the highest production standards from high quality materials. All Melling high volume oil pumps use the latest in gear and gerotor technology to provide the highest level of quality and performance. High volume gears are machined to close tolerances to ensure proper engine pressure and correct, efficient pump operation. End plates are precision ground for maximum wear resistance. Every Melling oil pump is individually tested for pressure and flow under conditions designed to duplicate actual engine operating conditions
Application summary
| Year | Make / model |
|---|---|
| 2002-2006 | Chevrolet Avalanche 2500 |
| 1991 | Chevrolet B60 |
| 1993-2002 | Chevrolet B7 |
| 1991-1993 | Chevrolet C1500 |
| 1991-2000 | Chevrolet C2500 |
| 1992-1999 | Chevrolet C2500 Suburban |
| 1991-2000 | Chevrolet C3500 |
| 1991-2002 | Chevrolet C3500HD |
| 2003-2009 | Chevrolet C4500 Kodiak |
| 1991 | Chevrolet C5500 Kodiak |
| 2003-2009 | Chevrolet C5500 Kodiak |
| 1991-1996 | Chevrolet C60 Kodiak |
| 1997-2009 | Chevrolet C6500 Kodiak |
| 1991-1996 | Chevrolet C70 Kodiak |
| 1997-2009 | Chevrolet C7500 Kodiak |
| 1996-2002 | Chevrolet Express 3500 |
| 1991-1996 | Chevrolet G30 |
| 1991-2000 | Chevrolet K2500 |
| 1992-1999 | Chevrolet K2500 Suburban |
| 1991-2000 | Chevrolet K3500 |
| 1991-1999 | Chevrolet P30 |
| 1992-1996 | Chevrolet P60 |
| 1992-1996 | Chevrolet P6000 |
| 1991 | Chevrolet R2500 Suburban |
| 1991 | Chevrolet R3500 |
| 2001-2006 | Chevrolet Silverado 2500 HD |
| 2007 | Chevrolet Silverado 2500 HD Classic |
| 2001-2006 | Chevrolet Silverado 3500 |
| 2007 | Chevrolet Silverado 3500 Classic |
| 2001-2006 | Chevrolet Suburban 2500 |
| 1997-1998 | Chevrolet T6500 |
| 1997-1998 | Chevrolet T7500 |
| 1991 | Chevrolet V3500 |
| 1991 | GMC B6000 |
| 1993-2002 | GMC B7 |
| 1991-2000 | GMC C2500 |
| 1992-1999 | GMC C2500 Suburban |
| 1991-2000 | GMC C3500 |
| 1991-2002 | GMC C3500HD |
| 2003-2009 | GMC C4500 Topkick |
| 1991 | GMC C5000 Topkick |
| 2003-2009 | GMC C5500 Topkick |
| 1991-1996 | GMC C6000 Topkick |
| 1997-2009 | GMC C6500 Topkick |
| 1991-1996 | GMC C7000 Topkick |
| 1997-2009 | GMC C7500 Topkick |
| 1991-1996 | GMC G3500 |
| 1991-2000 | GMC K2500 |
| 1992-1999 | GMC K2500 Suburban |
| 1991-2000 | GMC K3500 |
| 1991-1999 | GMC P3500 |
| 1992-1996 | GMC P6500 |
| 1991 | GMC R2500 Suburban |
| 1991 | GMC R3500 |
| 1996-2002 | GMC Savana 3500 |
| 2001-2006 | GMC Sierra 2500 HD |
| 2007 | GMC Sierra 2500 HD Classic |
| 2001-2006 | GMC Sierra 3500 |
| 2007 | GMC Sierra 3500 Classic |
| 1997-1998 | GMC T6500 |
| 1997-1998 | GMC T7500 |
| 1991 | GMC V3500 |
| 2001-2006 | GMC Yukon XL 2500 |
Specifications
- GTIN
- 00729295103974
- Weight
- 5.5 lb
- Height
- 4.75 in
- Length
- 10.75 in
- Width
- 6.25 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- MEL
- Warehouse brand code
- BCBC
- AAIA brand code
- BCBC
Attributes
- Bolts Included
- No
- Bushing Included
- No
- California Proposition 65
- No
- Cotter Pin Included
- No
- Cover Material
- Cast Iron
- Drive Shaft Included
- No
- Drive Type
- Drive Shaft
- Finish
- Rust Preventative
- Gasket Or Seal Included
- No
- Gear Material
- Steel
- Gears Included
- Yes
- Governor Spinner Included
- No
- Grade Type
- Improved Design
- Guide Included
- Yes
- Height
- 4.51
- Housing Material
- Cast Iron
- Inlet Size (in)
- 0.750
- Inlet Size (mm)
- 19.00
- Intermediate Shaft Included
- No
- Mounting Hole Diameter
- 0.25
- Mounting Hole Quantity
- 2
- Nylon Bushing Included
- No
- O-Ring Included
- No
- Oil Pump Type
- Gear
- Pick Up Tube Diameter
- 0.75
- Pickup Screen Included
- Yes
- Pump Cover Included
- Yes
- Shaft Material
- Not Applicable
- Spacer Included
- No
- Timing Cover Included
- No
- Title
- Engine Oil Pump
- Washers Included
- No
- Width
- 4.5
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
2002-2006 Chevrolet Avalanche 2500; 1991 Chevrolet B60; 1993-2002 Chevrolet B7; 1991-1993 Chevrolet C1500; 1991-2000 Chevrolet C2500; 1992-1999 Chevrolet C2500 Suburban; 1991-2000 Chevrolet C3500; 1991-2002 Chevrolet C3500HD; 2003-2009 Chevrolet C4500 Kodiak; 1991 Chevrolet C5500 Kodiak; 2003-2009 Chevrolet C5500 Kodiak; 1991-1996 Chevrolet C60 Kodiak; 1997-2009 Chevrolet C6500 Kodiak; 1991-1996 Chevrolet C70 Kodiak; 1997-2009 Chevrolet C7500 Kodiak; 1996-2002 Chevrolet Express 3500; 1991-1996 Chevrolet G30; 1991-2000 Chevrolet K2500; 1992-1999 Chevrolet K2500 Suburban; 1991-2000 Chevrolet K3500; 1991-1999 Chevrolet P30; 1992-1996 Chevrolet P60; 1992-1996 Chevrolet P6000; 1991 Chevrolet R2500 Suburban; 1991 Chevrolet R3500; 2001-2006 Chevrolet Silverado 2500 HD; 2007 Chevrolet Silverado 2500 HD Classic; 2001-2006 Chevrolet Silverado 3500; 2007 Chevrolet Silverado 3500 Classic; 2001-2006 Chevrolet Suburban 2500; 1997-1998 Chevrolet T6500; 1997-1998 Chevrolet T7500; 1991 Chevrolet V3500; 1991 GMC B6000; 1993-2002 GMC B7; 1991-2000 GMC C2500; 1992-1999 GMC C2500 Suburban; 1991-2000 GMC C3500; 1991-2002 GMC C3500HD; 2003-2009 GMC C4500 Topkick; 1991 GMC C5000 Topkick; 2003-2009 GMC C5500 Topkick; 1991-1996 GMC C6000 Topkick; 1997-2009 GMC C6500 Topkick; 1991-1996 GMC C7000 Topkick; 1997-2009 GMC C7500 Topkick; 1991-1996 GMC G3500; 1991-2000 GMC K2500; 1992-1999 GMC K2500 Suburban; 1991-2000 GMC K3500; 1991-1999 GMC P3500; 1992-1996 GMC P6500; 1991 GMC R2500 Suburban; 1991 GMC R3500; 1996-2002 GMC Savana 3500; 2001-2006 GMC Sierra 2500 HD; 2007 GMC Sierra 2500 HD Classic; 2001-2006 GMC Sierra 3500; 2007 GMC Sierra 3500 Classic; 1997-1998 GMC T6500; 1997-1998 GMC T7500; 1991 GMC V3500; 2001-2006 GMC Yukon XL 2500
