Melling Engine Parts / Melling Tool Co. · M-54D-S
Part #: M-54D-S
UPC: 729295100577
Loading...
Notify me when this item is in stock.
Description: Stock Replacement Oil Pump With Screen; M-54D-S Stock Replacement : Standard Volume, Standard Pressure, Cast Iron Oil Pump With Gasket
Description:
Description
Made in USA. Melling oil pumps provide dependable performance every time in every application. Every Melling oil pump is engineered and assembled to the highest production standards from high quality materials. All Melling oil pumps use the latest in gear and gerotor technology to provide the highest level of quality and performance. Gears are machined to close tolerances to ensure proper engine pressure and correct, efficient pump operation. End plates are precision ground for maximum wear resistance. Every Melling oil pump is individually tested for pressure and flow under conditions designed to duplicate actual engine operating conditions.
Features & benefits
- Manufactured from high quality materials for consistent durable wear
- Designed for long-life and worry-free performance
- Meets or exceeds original equipment specifications
- Precision engineered for optimum fit and function
Application summary
| Year | Make / model |
|---|---|
| 1979-1981 | Buick Century |
| 1980 | Buick Electra |
| 1980 | Buick Estate Wagon |
| 1977-1980 | Buick LeSabre |
| 1979-1981 | Buick Regal |
| 1977 | Buick Skylark |
| 1975 | Oldsmobile 98 |
| 1975 | Oldsmobile Custom Cruiser |
| 1975 | Oldsmobile Delta 88 |
| 1979 | Oldsmobile Delta 88 |
| 1968-1971 | Pontiac Acadian |
| 1968-1969 | Pontiac Beaumont |
| 1959-1981 | Pontiac Bonneville |
| 1959-1981 | Pontiac Catalina |
| 1967-1970 | Pontiac Executive |
| 1967-1981 | Pontiac Firebird |
| 1973-1975 | Pontiac Grand Am |
| 1978-1980 | Pontiac Grand Am |
| 1975-1977 | Pontiac Grand LeMans |
| 1979-1981 | Pontiac Grand LeMans |
| 1962-1981 | Pontiac Grand Prix |
| 1971-1978 | Pontiac Grand Safari |
| 1972-1975 | Pontiac Grandville |
| 1964-1973 | Pontiac GTO |
| 1967-1974 | Pontiac Laurentian |
| 1976-1977 | Pontiac Laurentian |
| 1981 | Pontiac Laurentian |
| 1963-1977 | Pontiac LeMans |
| 1979-1981 | Pontiac LeMans |
| 1967-1974 | Pontiac Parisienne |
| 1976 | Pontiac Parisienne |
| 1981 | Pontiac Parisienne |
| 1959-1966 | Pontiac Star Chief |
| 1969-1970 | Pontiac Strato-Chief |
| 1961-1970 | Pontiac Tempest |
| 1960-1961 | Pontiac Ventura |
| 1971-1975 | Pontiac Ventura |
| 1977 | Pontiac Ventura |
Specifications
- GTIN
- 00729295100577
- Weight
- 5.42 lb
- Height
- 5.25 in
- Length
- 8 in
- Width
- 6 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- MEL
- Warehouse brand code
- BCBC
- AAIA brand code
- BCBC
Attributes
- Bolts Included
- No
- Bushing Included
- No
- California Proposition 65
- No
- Cotter Pin Included
- No
- Cover Material
- Cast Iron
- Drive Shaft Included
- No
- Drive Type
- Drive Shaft
- Finish
- Rust Preventative
- Gasket Or Seal Included
- Yes
- Gear Material
- Steel
- Gears Included
- Yes
- Governor Spinner Included
- No
- Grade Type
- Standard Replacement
- Guide Included
- No
- Height
- 6.25
- Housing Material
- Cast Iron
- Inlet Size (in)
- 0.750
- Inlet Size (mm)
- 19.00
- Intermediate Shaft Included
- No
- Mounting Hole Diameter
- 0.375
- Mounting Hole Quantity
- 2
- Nylon Bushing Included
- No
- O-Ring Included
- No
- Oil Pump Type
- Gear
- Pick Up Tube Diameter
- 0.75
- Pickup Screen Included
- Yes
- Pump Cover Included
- Yes
- Shaft Material
- Not Applicable
- Spacer Included
- No
- Timing Cover Included
- No
- Title
- Engine Oil Pump
- Washers Included
- No
- Width
- 3.68
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1979-1981 Buick Century; 1980 Buick Electra; 1980 Buick Estate Wagon; 1977-1980 Buick LeSabre; 1979-1981 Buick Regal; 1977 Buick Skylark; 1975 Oldsmobile 98; 1975 Oldsmobile Custom Cruiser; 1975 Oldsmobile Delta 88; 1979 Oldsmobile Delta 88; 1968-1971 Pontiac Acadian; 1968-1969 Pontiac Beaumont; 1959-1981 Pontiac Bonneville; 1959-1981 Pontiac Catalina; 1967-1970 Pontiac Executive; 1967-1981 Pontiac Firebird; 1973-1975 Pontiac Grand Am; 1978-1980 Pontiac Grand Am; 1975-1977 Pontiac Grand LeMans; 1979-1981 Pontiac Grand LeMans; 1962-1981 Pontiac Grand Prix; 1971-1978 Pontiac Grand Safari; 1972-1975 Pontiac Grandville; 1964-1973 Pontiac GTO; 1967-1974 Pontiac Laurentian; 1976-1977 Pontiac Laurentian; 1981 Pontiac Laurentian; 1963-1977 Pontiac LeMans; 1979-1981 Pontiac LeMans; 1967-1974 Pontiac Parisienne; 1976 Pontiac Parisienne; 1981 Pontiac Parisienne; 1959-1966 Pontiac Star Chief; 1969-1970 Pontiac Strato-Chief; 1961-1970 Pontiac Tempest; 1960-1961 Pontiac Ventura; 1971-1975 Pontiac Ventura; 1977 Pontiac Ventura
