Manley · 23675-16
Part #: 23675-16
UPC: 807298039510
Log in for inventory
Notify me when this item is in stock.
Description: Ti Retainers-11/32", 3/8" stem diam. 7 DEG vlv lck, 1.325" OD, +.100" inst. hgt; Height: +.100 in. - Spring Diameter: 1.500 in. - Valve Stem Diameter: 11/32 in. - Weight: 14.0 grams
Description:
Description
Upgrade your valve train with Manley Performance Titanium Retainers and other lightweight titanium options designed specifically for high-revving engines. Machined from aerospace-grade heat-treated 6AL-4V titanium, these retainers dramatically reduce valvetrain mass for quicker rev-up, improved valve control and enhanced overall responsiveness. The reduced weight helps your engine hold spring pressure at high RPM, minimizing float and unlocking more performance potential in race or aggressive street applications. Lightweight, strong, and precision-built for serious performance.
Features & benefits
- CAD designed for ultimate reduction in mass without sacrificing strength
- Must use 7 valve locks
- Use Manley P/N 13098 (recommended) or factory Chevrolet LT valve locks
- Sames as 23623 but +.055" more installed height
- Sames as 23628 dimensionally except made of Titanium
- Special 6AL-4V titanium for maximum strength
Information
Manley Spring Retainer, Titanium, 1.500 DOUBLE 7 DEG
Specifications
- GTIN
- 00807298039510
- Weight
- 1.25 lb
- Height
- 0.5 in
- Length
- 10.75 in
- Width
- 6.75 in
- EO
- Offroad
- Life cycle
- Available to Order
- Warehouse brand code
- BBPB
- AAIA brand code
- BBPB
Attributes
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Category Hierarchy
- Valvetrain Components>Spring Retainers>Titanium
- EBAY Category ID
- 262140
- Engine Type
- ICE
- First Step Diameter
- 1.325
- Height
- +.100
- Industry
- Automotive
- Out of Stock Message
- Call for Availability
- Product Market
- Domestic
- Product Type
- Engine Valve Spring Retainer Set
- Quantity
- 16
- Second Step Diameter
- 1.035
- Stem Diameter
- 11/32, 3/8
- Third Step Diameter
- 0.705
- Title
- Manley Titanium 7 Degree Valve Spring Retainer - Use with Manley Spring 221420, 221455, 221456, 221457, 221460, 221461
- Title - Web
- Manley Titanium 7 Degree Valve Spring Retainer - Use with Manley Spring 221420, 221455, 221456, 221457, 221460, 221461
- Valve Lock Angle
- 7
- Valve Lock Degree
- 7
- Valve Spring
- Manley 221420, 1455, 1456, 1457, 1460, 1461
- Valve Spring Outer Diameter
- 1.500
- Valve Spring Retainer Material
- 6AL-4V Titanium
- Valve Spring Retainer Quantity
- 16
- Valve Spring Retainer Series
- 7 Degree Titanium
- Valve Stem Diameter
- 11/32, 3/8
- Weight
- 15
Fitment status
This product is universal and will fit your application.
