Manley · 23670TM-16
Part #: 23670TM-16
UPC: 807298039152
Log in for inventory
Notify me when this item is in stock.
Description: Manley Spring Retainer, TensileMax SUPER 7 1.550
Description:
Description
Manley TensileMax Steel Retainers combine exceptional strength, fatigue resistance, and wear durability in a lightweight design that approaches titanium retainer weights. Manufactured from a proprietary TensileMax alloy, precision CNC machined, heat treated, and finished with Manley exclusive impingement process, they deliver reliable high-RPM valvetrain performance for demanding racing and performance engine applications.
Features & benefits
- Manufactured from our incredibly tough TensileMax alloy
- Designed to be as light as standard titanium retainers and very close in weight to lightweight titanium versions (within 2-4 grams)
- Specially heat treated to provide a hardness of Rc 52-54 and prevent retainer wear
- Optimum balance between ultimate strength, fatigue strength, hardness, and ductility
- Unique impingement process that improves fatigue strength and promotes better oiling between the spring and retainer
Information
Manley Spring Retainer, RET-TENSILE MAX SUPER 7 1.550
Specifications
- GTIN
- 00807298039152
- Weight
- 1.25 lb
- Height
- 0.5 in
- Length
- 10.75 in
- Width
- 6.75 in
- EO
- Offroad
- Life cycle
- Available to Order
- Warehouse brand code
- BBPB
- AAIA brand code
- BBPB
Attributes
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Category Hierarchy
- Valvetrain Components>Spring Retainers>Steel
- EBAY Category ID
- 262140
- Engine Type
- ICE
- First Step Diameter
- 1.420
- Industry
- Automotive
- Out of Stock Message
- Call for Availability
- Product Market
- Domestic
- Product Type
- Engine Valve Spring Retainer Set
- Second Step Diameter
- 1.105
- Third Step Diameter
- 0.710
- Title
- Manley Spring Retainer, RET-TENSILE MAX SUPER 7 1.550
- Title - Web
- Manley Spring Retainer, RET-TENSILE MAX SUPER 7 1.550
- Valve Lock Angle
- Super 7
- Valve Lock Degree
- Super 7
- Valve Spring
- Manley 22431, 22440, 22441
- Valve Spring Outer Diameter
- 1.550
- Valve Spring Retainer Material
- TensileMax Alloy
- Valve Spring Retainer Quantity
- 16
- Valve Spring Retainer Series
- TensileMax Steel Retainers
- Valve Spring Type
- Double
- Weight
- 20
Fitment status
This product is universal and will fit your application.
