K&N · 69-8522TS
Part #: 69-8522TS
UPC: 024844093691
Log in for inventory
Notify me when this item is in stock.
This is a message from K&N on the BRAND, not a CAtegory.
This is a Test Product Message for the Air Intakes Category!
Description: Performance Air Intake System; K&N's easy-to-install Typhoon air intake system replaces the restrictive factory air filter and air intake housing delivering a guaranteed power gain. The low-restriction aluminum intake tube comes in a silver powder coat finish.
Description:
This part number superseded 69-8522TB.
Description
The K&N 69-8522TS Typhoon air intake system is a free-flowing, mandrel-bent aluminum tube air induction system designed to fit some Toyota Celica GTS models. The restrictive factory air filter and air intake housing are replaced by the K&N Typhoon air intake which is designed to dramatically reduce air flow restriction as it smoothes and straightens air flow. This allows your engine to inhale a larger amount of air than the factory air intake. More air means more usable power and acceleration throughout the engine's RPM range. The 69-8522TS air intake comes with a black rubber topped K&N high-flow air filter that installs into the previous air box space. Air is directed through the intake tube into the engine's throttle body for a guaranteed power gain. The intake tube has an attractive silver powder-coat finish that's made to last and it accommodates the factory mass air sensor and EVAP vent hose. The oversized cone shaped air filter can be used for up to 100,000 miles before servicing is needed depending on driving conditions. This air intake is relatively easy to install usually in 90 minutes or less. ach vehicle and air intake.
Features & benefits
- Guaranteed to increase horsepower
- Designed to improve throttle response and engine sound
- Free-flowing aluminum tube
- Easy to install, usually in 90 minutes or less
- Filter lasts up to 100,000 miles before service is required
- Replaces entire factory air intake system
- Washable and reusable lifetime air filter
- K&N Million Mile Limited Warranty
Information
Associated products: RX-4730DK Air Filter Wrap, RU-4870 Universal Clamp-On Air Filter, 99-5000 Filter Care Service Kit Aerosol
Application summary
| Year | Make / model |
|---|---|
| 2000-2004 | Toyota Celica |
Specifications
- GTIN
- 00024844093691
- Weight
- 6.5 lb
- Height
- 8.5 in
- Length
- 18.25 in
- Width
- 14.5 in
- EO
- Legal US
- Life cycle
- Discontinued
- Alt. part number
- 69-8522TS
- AAM brand code
- KAN
- Warehouse brand code
- KAN
- AAIA brand code
- BBWQ
Attributes
- AAM Standard Pack
- 1
- Air Box Included
- No
- Air Filter Color
- Red
- Air Filter Element Washable
- Yes
- Air Filter Height
- 6.5 in (165 mm)
- Air Filter Large End Diameter
- 6 in (152 mm)
- Air Filter Material
- Cotton Gauze
- Air Filter Oulet Length
- 2.750 in. (70mm)
- Air Filter Oulet Width
- 2.750 in. (70mm)
- Air Filter Outlet Length
- 2.75 in (70 mm)
- Air Filter Outlet Shape
- Round
- Air Filter Outlet Width
- 2.75 in (70 mm)
- Air Filter Washable
- Yes
- Alternate Part Number
- 69-8522TS
- Base Outside Diameter
- 6 in (152 mm)
- CARB EO Number
- D-269-30
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Clamp Color
- Natural
- Clamp Color/Finish
- Natural
- Clamp Material
- Stainless Steel
- Clamp Quantity
- 3
- Clamp Style
- Regular
- Clamps Included
- 3
- Coupler Color
- Black
- Coupler Color/Finish
- Black
- Couplers Included
- 1
- Estimated Horse Power Gain
- 7.53 HP @ 6362 RPM
- Estimated Horsepower Gain
- 7.53 HP @ 6362 RPM
- Estimated Torque Gain
- 6 lbft
- Filter Color
- Red
- Filter Material
- Cotton Gauze
- Flange Angle
- 0 Degree
- Flange Inside Diameter
- 2.75 in (70 mm)
- Flange Length
- 2 in (51 mm)
- Flange Offset
- 0.000 in. (0mm)
- Flange Type
- Centered
- Height
- 6.5 in (165 mm)
- Horse Power Increase
- 8 HP
- Intake Pipe Color
- Silver
- Intake Pipe Color / Finish
- Silver
- Intake Pipe Inlet Length
- 16.000 in. (406mm)
- Intake Pipe Inlet Shape
- Round
- Intake Pipe Inlet Width
- 2.750 in. (70mm)
- Intake Pipe Material
- Aluminum
- Intake Pipe Outlet Length
- 16.000 in. (406mm)
- Intake Pipe Outlet Shape
- Round
- Intake Pipe Outlet Width
- 2.750 in. (70mm)
- Intake Pipe Ports
- All intake tube ports needed for the specified applications are included
- Item Height
- 6.500 in. (165mm)
- Item Weight
- 6.500 lbs. (3 kg)
- Mass Air Flow Sensor Adapter Included
- Yes
- Mass Air Flow Sensor Included
- Mass Air Flow Sensor Adapter Included When Required
- Mounting Hardware Included
- Yes
- Oil Included
- Filter Is Pre-Oiled
- Package Material
- Paperboard
- Package Type
- Box
- Product Box Height
- 8.5 in (216 mm)
- Product Box Length
- 18.25 in (464 mm)
- Product Box Width
- 14.5 in (368 mm)
- Product Style
- 69 Series Typhoon Kits
- RPM
- 6362
- Replacement Filter
- RU-4870
- Retail Packaging
- Yes
- Street Legal
- Yes
- Street Legal In All US States
- Legal for use in all 50 states.
- System Type
- Short-Ram Intake System
- TUV Approved (Europe)
- No
- Title
- K&N 69-8522TS Performance Air Intake System
- Top Material
- None
- Top Material/Finish
- None
- Top Outside Diameter
- 5 in (127 mm)
- Top Style
- X-Stream
- Warranty
- No-Hassle Lifetime Limited
- Weight
- 6.5 lb (3 kg)
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
2000-2004 Toyota Celica
