K&N · 57-2561
Part #: 57-2561
UPC: 024844109156
Log in for inventory
Notify me when this item is in stock.
This is a message from K&N on the BRAND, not a CAtegory.
This is a Test Product Message for the Air Intakes Category!
Description: Performance Air Intake System; K&N's roto-molded cold air intake systems are guaranteed to provide an increase in horsepower and torque, and are protected by the K&N No-Hassle Lifetime Limited Warranty.
Description:
This part number superseded 63-1108.
Description
A high-density polyethylene (HDPE) rotationally-molded tube helps increase the volume of airflow to your engine, and provides a guaranteed increase in horsepower and torque. These systems are paired with a washable, reusable High-Flow Air Filter featuring oiled cotton filter media. The oversized, conical design allows you to go up to 100,000 miles between filter services under normal highway driving conditions. A custom heat shield helps protect intake air from the high temperature of your engine bay, and the entire system can typically be installed in less than 60 minutes.
Features & benefits
- Guaranteed to increase horsepower and torque
- Roto-molded HDPE intake tube paired with oversized oiled cotton air filter
- Engineered to provide high airflow and exceptional filtration
- Replaces factory air filter and intake tube
- Filter only requires cleaning every 100,000 miles under normal highway driving conditions
- Typical installation can be completed in 60 minutes or less with simple hand tools
- No-Hassle Lifetime Limited Warranty™
- Will not void vehicle warranty
Information
Associated products: RX-4990DK Air Filter Wrap, RX-4990DL Air Filter Wrap, RX-4990DR Air Filter Wrap, RX-4990DY Air Filter Wrap, RU-4990 Universal Clamp-On Air Filter, 99-5000 Filter Care Service Kit Aerosol
Application summary
| Year | Make / model |
|---|---|
| 2004-2011 | Ford Ranger |
| 2004-2009 | Mazda B4000 |
Specifications
- GTIN
- 00024844109156
- Weight
- 8.3 lb
- Height
- 12.25 in
- Length
- 20.25 in
- Width
- 12.25 in
- EO
- Legal US
- Life cycle
- Available to Order
- Alt. part number
- 57-2561
- AAM brand code
- KAN
- Warehouse brand code
- KAN
- AAIA brand code
- BBWQ
Attributes
- AAM Standard Pack
- 1
- Air Box Included
- No
- Air Filter Color
- Red
- Air Filter Element Washable
- Yes
- Air Filter Height
- 5.563 in. (141mm)
- Air Filter Large End Diameter
- 6.000 in. (152mm)
- Air Filter Material
- Cotton Gauze
- Air Filter Oulet Length
- 3.000 in. (76mm)
- Air Filter Oulet Width
- 3.000 in. (76mm)
- Air Filter Outlet Length
- 3.000 in. (76mm)
- Air Filter Outlet Shape
- Round
- Air Filter Outlet Width
- 3.000 in. (76mm)
- Air Filter Washable
- Yes
- Alternate Part Number
- 57-2561
- CARB EO Number
- D-269-48
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Clamp Color
- Natural
- Clamp Color/Finish
- Natural
- Clamp Material
- Stainless Steel
- Clamp Quantity
- 3
- Clamp Style
- Regular
- Clamps Included
- 3
- Coupler Color
- Black
- Coupler Color/Finish
- Black
- Couplers Included
- 1
- Estimated Horse Power Gain
- 13.46 HP @ 5129 RPM
- Estimated Horsepower Gain
- 13.46 HP @ 5129 RPM
- Estimated Torque Gain
- 14 lbft
- Filter Color
- Red
- Filter Material
- Cotton Gauze
- Horse Power Increase
- 13 HP
- Intake Pipe Color
- Black
- Intake Pipe Color / Finish
- Black
- Intake Pipe Material
- High-Density Cross-Linked Polyethylene
- Intake Pipe Ports
- All intake tube ports needed for the specified applications are included
- Item Weight
- 8.300 lbs. (3.8 kg)
- Mass Air Flow Sensor Adapter Included
- Yes
- Mass Air Flow Sensor Included
- Mass Air Flow Sensor Adapter Included When Required
- Mounting Hardware Included
- Yes
- Oil Included
- Filter Is Pre-Oiled
- Package Material
- Paperboard
- Package Type
- Box
- Product Box Height
- 12.250 in. (311mm)
- Product Box Length
- 20.250 in. (514mm)
- Product Box Width
- 12.250 in. (311mm)
- Product Style
- 57 Series FIPK
- RPM
- 5129
- Replacement Filter
- RU-4990
- Retail Packaging
- No
- Street Legal
- Yes
- Street Legal In All US States
- Legal for use in all 50 states.
- TUV Approved (Europe)
- No
- Title
- K&N 57-2561 Performance Air Intake System
- Type
- Gen II
- Warranty
- No-Hassle Lifetime Limited
- Weight
- 8.3 lb (3.8 kg)
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
2004-2011 Ford Ranger; 2004-2009 Mazda B4000
Equivalent Parts
K&N 57-2561
