JE Pistons / SRP · 362143S
Part #: 362143S
UPC: 193564210807
Log in for inventory
Notify me when this item is in stock.
Description: PORSCHE M96.70/M97.70; JE, Porsche, Watercooled - 6 Cyl, 3.937 in. Bore, 9.40:1, Flat Top, Single Piston
Description:
Description
JE Pistons is the leader in forged racing pistons. With 70-plus years of experience, in-house forging, and industry-leading technology, JE Pistons are designed to perform at the top levels of all forms of motorsports.
Features & benefits
- Forged in the USA using 2618 aluminum, yielding high tensile strength needed for high-demand performance applications
- Designed specifically for each engine and use application to provide optimized performance durability
Specifications
- GTIN
- 00193564210807
- Weight
- 1.4 lb
- Height
- 5 in
- Length
- 5 in
- Width
- 5 in
- EO
- Offroad
- Life cycle
- Available to Order
- Warehouse brand code
- JEP
- AAIA brand code
- BHXG
Attributes
- Add-On
- 905-073-MW
- Bore Diameter
- 100.00
- Bore Diameter - Web
- 100.00 MM
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Category Hierarchy
- Auto>JE Pistons>Single Replacement Pistons>European
- Compression Height
- 1.303
- Cylinder Head
- 997 TT
- Engine
- 3.6L Watercooled
- Engine - Web
- 3.6L Watercooled
- Engine Type
- ICE
- Forging Type
- FSR
- Industry
- Automotive
- Make
- PORSCHE
- Make - Web
- Porsche
- Oil Ring Thickness
- 0.079
- Out of Stock Message
- Please Allow Approximately 3 Weeks or Less for Shipping
- Piston Head Type
- Flat
- Piston Material
- 2618
- Piston Pin Length
- 2.250
- Piston Pin Material
- 9310
- Piston Pin Outside Diameter
- 0.905
- Piston Pin Wall Thickness
- 0.210
- Piston Quantity
- 1
- Piston Qunatity
- 1
- Piston Series
- JE Pistons
- Piston Volume
- -25.00
- Product Market
- European
- Product Type
- Engine Piston
- Ring Set Included
- Yes
- Ringset Included
- Yes
- Second Compression Ring Thickness
- 0.0480
- Title
- JE Pistons - Porsche, 3.6L Watercooled, 100.00 mm Bore, Piston
- Title - Web
- JE Pistons Porsche 3.6L Watercooled Piston - 100.00 mm Bore - 1.303 in. CH, -25.00 CC
- Top Compression Ring Thickness
- 0.0383
- Wrist Pin Length
- 2.250
- Wrist Pin Material
- 9310
- Wrist Pin Outer Diameter
- 0.905
- Wrist Pin Wall Thickness
- 0.210
Fitment status
This product is universal and will fit your application.
Application summary
Porsche 3.6L M96.70/M97.70 996 Turbo
