JE Pistons / SRP · 360832L
Part #: 360832L
UPC: 193564198990
Log in for inventory
Notify me when this item is in stock.
Description: COYOTE 5.0 ULTRA SERIES 11.0:1; JE Ultra, Ford, Modular Ford, 3.650 in. Bore, 1.174 CD, Dome, Left Piston
Description:
Description
JE Pistons Ultra Series pistons combine all of the best, most desirable piston features, such as thermal barrier crown coating, lateral gas ports, thick-wall wrist pins, and a revolutionary new forging technology for the ultimate in strength. They are ready for massive power and boost right out of the box!
Features & benefits
- Designed for Power: Every feature on Ultra Series Pistons are optimized to perform flawlessly in high high-horsepower racing engines. This includes lateral gas ports, thicker ring lands, and dual pin oiling
- Aligned Grain Flo
Specifications
- GTIN
- 00193564198990
- Weight
- 1.4 lb
- Height
- 5 in
- Length
- 5 in
- Width
- 5 in
- EO
- Offroad
- Life cycle
- Available to Order
- Warehouse brand code
- JEP
- AAIA brand code
- BHXG
Attributes
- Add-On
- 866-063-MW
- Bore Diameter
- 3.650
- Bore Diameter - Web
- 3.650 IN
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Category Hierarchy
- Auto>JE Ultra Series>Single Replacement Pistons>Domestic
- Compression Height
- 1.174
- Cylinder Head
- MODULAR 5.0L COYOTE GEN 1/2
- Engine
- Modular
- Engine - Web
- Modular
- Engine Type
- ICE
- Forging Type
- FSR
- Industry
- Automotive
- Make
- FORD
- Make - Web
- Ford
- Oil Ring Thickness
- 0.111
- Out of Stock Message
- Please Allow Approximately 3 Weeks or Less for Shipping
- Piston Head Type
- Dome
- Piston Material
- 2618
- Piston Orientation
- Left
- Piston Pin Length
- 2.250
- Piston Pin Material
- 9310
- Piston Pin Outside Diameter
- 0.866
- Piston Pin Wall Thickness
- 0.230
- Piston Series
- JE Pistons
- Piston Volume
- 1.90
- Product Market
- Domestic
- Product Type
- Engine Piston
- Ring Set Included
- No
- Ringset Included
- No
- Second Compression Ring Thickness
- 0.0480
- Title
- JE Ultra Series - Ford, Modular, 3.650 in. Bore, Piston
- Title - Web
- JE Ultra Series Ford Modular Piston - 3.650 in. Bore - 1.174 in. CH, 1.90 CC
- Top Compression Ring Thickness
- 0.0395
- Wrist Pin Length
- 2.250
- Wrist Pin Material
- 9310
- Wrist Pin Outer Diameter
- 0.866
- Wrist Pin Wall Thickness
- 0.230
Fitment status
This product is universal and will fit your application.
Application summary
Ford 5.0L Coyote
Resources
JE Pistons / SRP 360832L
