ICON Vehicle Dynamics / 73002
Part #: 73002
UPC: 840103436142
Loading...
Notify me when this item is in stock.
Description: 20-26 GM 2500/3500 HD IIC INSTALL KIT; ICON Intelligent Control (IIC) monitors, analyzes, and processes data in real-time. Info from the onboard G-force sensor and Gyroscope perform calculations based on algorithms and user-defined settings to predict terrain and wheel position.
Description:
Description
The IIC App brings all of this technology together by offering a user-friendly interface to monitor, record, and adjust the system’s performance via Bluetooth connection. Users can easily alter the shocks’ baseline settings for firmness, as well as adjust the sensitivity of vertical “G-Boost” and lateral “Corner Boost” with a few simple taps from their favorite iOS device. The App includes several preconfigured ‘Drive Modes’ (Normal, Desert, and Haul) but also offers the ability for users to create an unlimited number of unique presets using their own custom settings. To top it all off, you can record data from your trip including time, speed, distance and G-Forces for your very own ICONIC Overview.
Features & benefits
- Offers selectable active shock damping adjustment as well as manual adjustment of baseline settings without exiting vehicle
- Onboard sensors monitor G-forces and movement of vehicle chassis
- Performs calculations based on sensor inputs, custom algorithms, and user defined settings at a rate of over 1000 times per second
- Sends necessary damping adjustments to CDEV shocks that react in under 40 milliseconds
- User interface provided by IIC Mobile App via Bluetooth connection to iOS device
- Mobile app offers preconfigured “Drive Modes” as well as the ability to create custom presets
- Also functions as a data logger for time, speed, distance, and G-force allowing you to record data from your trips
- Application specific mounting brackets, hardware and wire harnesses
Information
APPLICATION NOTE #207: Also requires installation of applicable CDEV front and rear shocks
Application summary
| Year | Make / model |
|---|---|
| 2020-2026 | Chevrolet Silverado 2500 HD |
| 2020-2026 | Chevrolet Silverado 3500 HD |
| 2020-2026 | GMC Sierra 2500 HD |
| 2020-2026 | GMC Sierra 3500 HD |
Specifications
- GTIN
- 00840103436142
- Weight
- 5 lb
- Height
- 5 in
- Length
- 19 in
- Width
- 9 in
- Life cycle
- Available to Order
- AAM brand code
- IVD
- Warehouse brand code
- FRDK
- AAIA brand code
- FRDK
Attributes
- AAP_UDA_12
- EA
- AAP_UDA_22
- 1
- AAP_UDA_4
- 55
- Add-On Part
- 77701EP - 20-26 GM 2500/3500 HD 0-1.5" REAR VS 2.5 PB CDEV PAIR
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Connector Gender
- Female
- Grade Type
- Performance
- Terminal Type
- Pin
- Title
- ICON 2020-2026 Chevrolet Silverado/GMC Sierra 2500/3500 HD, ICON Intelligent Control Install Kit
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
2020-2026 Chevrolet Silverado 2500 HD; 2020-2026 Chevrolet Silverado 3500 HD; 2020-2026 GMC Sierra 2500 HD; 2020-2026 GMC Sierra 3500 HD
