Hushmat · 629015
Part #: 629015
UPC: 881101290190
Log in for inventory
Notify me when this item is in stock.
Description: HushMat Custom Vehicle Sound Deadening and Thermal Insulation Roof Kit insulates your vehicle roof from radiant heat and rattles.
Description:
Description
Your Pick Up has power, performance, and style, but the roof can allow the cabin to heat up if it does not have the proper automotive heat shield. The roof is very thin metal and sun, rain and the elements hit it repeatedly. HushMat auto insulation is proven in an independent study to lower the temperature by over 40 percent. The roof of your car can vibrate sounding more like a drum. When driving in a rain storm you hear a constant sound of rain hitting the thin metal roof. Overtime this gets annoying and uncomfortable. HushMat eliminates the noise by eliminating the vibration. On sunny days especially in the summer months radiant heat from sun elevates your roof temperature to over 180 degrees. All you have to do to test this is touch the roof. Do it very quickly because it will burn you. Install the HushMat custom roof insulation kit and reduce that heat from entering the Pick Up by over 40 percent. HushMat automotive sound deadening mat reduces this noise and heat gives you a more comfortable ride. HushMat sound deadening and thermal insulation material leads the automotive industry in ease of installation. It is also number 1 Rated in performance. Packaged specifically for your Pick Ups year, make and model roof to provide 100 percent insulation coverage. There are no holes in the material and no puzzle pieces to put together. Simply apply the HushMat Ultra material as shown in the Installation Guide. HushMat auto insulation material reduces road noise, exhausts noise, and insulates your Pick Up for a more comfortable ride for you and your passengers. Nothing beats the heat or noise like HushMat. For additional heat and sound insulation consider adding the HushMat Silencer Megabond one quarter inch foam to the back of your headliner. Silencer Megabond, part number 22410, added with HushMat Custom Pick Up Roof Kit provides an additional 30 percent insulation to your Pick Up.
Features & benefits
- Reduce Heat Up to 40 Percent
- Ultra is 1.5mm and Lightweight at 0.47 lbs. Per Square Foot
- HushMat Ultra Requires No Heat Guns Or Messy Glue To Apply
- One-Step Application With HushMat Ultra-Simply Peel and Stick
- Reduce Noise Up to 50 Perfect
- Proven To Perform From -30 F To 550 F
- Manufactured in the USA for Over 25 years
- Eliminates Noise from Rain and Wind
- Reduces Radiant Heat from the Sun
- Automotive OEM Specified and Approved
- HushMat Ultra Requires No Pre-cleaning Of The Application Surface
- No More Acetone Or Alcohol Surface Preparation
Information
Reduce that aftermarket engine, exhaust drone, road noise, vibration and the noise that disrupts your ride and reduce the heat that comes from engine, headers, exhaust and catalytic converter with one USA Made material light weight HushMat Ultra
Application summary
| Year | Make / model |
|---|---|
| 1975-1986 | Chevrolet C10 |
| 1973-1974 | Chevrolet C10 Pickup |
| 1975-1986 | Chevrolet C20 |
| 1973-1974 | Chevrolet C20 Pickup |
| 1975-1986 | Chevrolet C30 |
| 1973-1974 | Chevrolet C30 Pickup |
| 1975-1986 | Chevrolet K10 |
| 1973-1974 | Chevrolet K10 Pickup |
| 1975-1986 | Chevrolet K20 |
| 1973-1974 | Chevrolet K20 Pickup |
| 1977-1986 | Chevrolet K30 |
| 1973-1974 | Chevrolet K30 Pickup |
| 1987 | Chevrolet R10 |
| 1987 | Chevrolet R20 |
| 1987 | Chevrolet R30 |
| 1987 | Chevrolet V10 |
| 1987 | Chevrolet V20 |
| 1987 | Chevrolet V30 |
| 1973-1974 | GMC C15/C1500 Pickup |
| 1973-1974 | GMC C25/C2500 Pickup |
| 1973-1974 | GMC C35/C3500 Pickup |
| 1973-1974 | GMC K15/K1500 Pickup |
| 1973-1974 | GMC K25/K2500 Pickup |
| 1973-1974 | GMC K35/K3500 Pickup |
Specifications
- GTIN
- 00881101290190
- Weight
- 14 lb
- Height
- 26 in
- Length
- 3 in
- Width
- 14 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- HSM
- Warehouse brand code
- HSM
- AAIA brand code
- FGSS
Attributes
- Add-On Part
- None
- California Proposition 65
- No
- Cold Flexibility
- Can be bent around 25 mm. mandrel at -30 degrees C with no cracking or loss of adhesion
- Color
- Polymer - Black; Backing - Silver
- Flammability
- Tested per FMVSS 302, HushMat Ultra is self-extinguishing and meets all aspects of the standard
- Hardness
- 6.5 - 9.0mm ?ASTM D-5
- Peel Strength
- Tested in 90 degree peel at a crosshead speed of 300mm per minute on a 25 mm wide test specimen. Average load in Newtons is reported.
- R-Value
- 7
- Safety
- HushMat Ultra is not considered a hazardous material. Care should be used in handling to avoid cuts from the foil. Gloves are recommended. The Material Safety Data Sheet is available upon request and should be read and understood before using this product.
- Shelf Life
- At least 6 months when stored at 40 degrees C or less
- Specific Gravity
- 1.47 (approx. 0.47 pounds per square foot)
- Temperature Resistance
- HUSHMAT ULTRA will withstand a bake of 1 hour at 240 degrees C with no deformation, sag, or flow when baked in horizontal, vertical or inverted positions.
- Thickness
- 1.5mm
- Title
- Auto Year Make and Model Roof Thermal Insulation and Deadener
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1975-1986 Chevrolet C10; 1973-1974 Chevrolet C10 Pickup; 1975-1986 Chevrolet C20; 1973-1974 Chevrolet C20 Pickup; 1975-1986 Chevrolet C30; 1973-1974 Chevrolet C30 Pickup; 1975-1986 Chevrolet K10; 1973-1974 Chevrolet K10 Pickup; 1975-1986 Chevrolet K20; 1973-1974 Chevrolet K20 Pickup; 1977-1986 Chevrolet K30; 1973-1974 Chevrolet K30 Pickup; 1987 Chevrolet R10; 1987 Chevrolet R20; 1987 Chevrolet R30; 1987 Chevrolet V10; 1987 Chevrolet V20; 1987 Chevrolet V30; 1973-1974 GMC C15/C1500 Pickup; 1973-1974 GMC C25/C2500 Pickup; 1973-1974 GMC C35/C3500 Pickup; 1973-1974 GMC K15/K1500 Pickup; 1973-1974 GMC K25/K2500 Pickup; 1973-1974 GMC K35/K3500 Pickup
Resources
Hushmat 629015
