Excel · GM75456TK
Part #: GM75456TK
UPC: 698231983270
Loading...
Notify me when this item is in stock.
Description: Precision Differential Ring and Pinion maintains correct power distribution to a; This Differential Ring and Pinion is precision manufactured to OEM gear ratios and tooth geometry. It distributes torque efficiently between axles, maximizing traction and minimizing wear in commercial trucks.
Description:
Description
Excel's broad line of original equipment automotive and light truck/SUV replacement ring & pinion gears, axles, and installation kits offer Richmond's high OEM quality at affordable prices. The Excel product line covers the most popular vehicles on the road today.
Features & benefits
- Designed for compatibility with OEM-specified gear oil viscosities, ensuring correct lubrication under all operating conditions.
- Heat-treated alloy steel construction withstands peak torque demands of loaded commercial trucks, preventing gear tooth fatigue and breakage.
- OEM-spec gear ratios preserve intended vehicle speed, performance, and fuel economy characteristics.
- Precision fits to carrier housing bores eliminate shimming uncertainty and simplify installation for experienced drivetrain technicians.
- Precision-machined gears and tight backlash tolerances ensure smooth power transfer and efficient torque distribution between axles.
Information
DIFFERENTIAL RING & PINION FOR GM 7.5"/7.625" (10 BOLT); 4.56 RATIO; THICK RING GEAR; REQUIRES A 3.23 & NUMERICALLY HIGHER RATIO CARRIER; REQUIRES NOTCHED CROSS SHAFT 80-0270-1 FOR OPEN CARRIERS FOR GM 7.6" IFS; 4.56 RATIO; THICK RING GEAR; REQUIRES
Application summary
| Year | Make / model |
|---|---|
| 1973-1975 | Buick Apollo |
| 1977-1981 | Buick Century |
| 1991-1996 | Buick Commercial Chassis |
| 1976-1989 | Buick Electra |
| 1977-1983 | Buick Estate Wagon |
| 1975-1989 | Buick LeSabre |
| 1977-1979 | Buick Opel |
| 1977-1987 | Buick Regal |
| 1977-1978 | Buick Riviera |
| 1991-1996 | Buick Roadmaster |
| 1975-1979 | Buick Skylark |
| 1987-1990 | Cadillac Brougham |
| 1982-1984 | Cadillac DeVille |
| 1982-1990 | Cadillac Fleetwood |
| 1985-2005 | Chevrolet Astro |
| 1995-2005 | Chevrolet Blazer |
| 1977-2002 | Chevrolet Camaro |
| 1977-1996 | Chevrolet Caprice |
| 2004-2013 | Chevrolet Colorado |
| 1991-1994 | Chevrolet Commercial Chassis |
| 1977-1987 | Chevrolet El Camino |
| 1977-1985 | Chevrolet Impala |
| 1994-1996 | Chevrolet Impala |
| 1975 | Chevrolet Malibu |
| 1978-1983 | Chevrolet Malibu |
| 1978-1988 | Chevrolet Monte Carlo |
| 1976-1979 | Chevrolet Nova |
| 1982-2004 | Chevrolet S10 |
| 1983-1994 | Chevrolet S10 Blazer |
| 1982-1987 | GMC Caballero |
| 2004-2012 | GMC Canyon |
| 2002-2005 | GMC Envoy |
| 2002-2005 | GMC Envoy XL |
| 2004-2005 | GMC Envoy XUV |
| 1992-2005 | GMC Jimmy |
| 1982-1990 | GMC S15 |
| 1983-1991 | GMC S15 Jimmy |
| 1985-2005 | GMC Safari |
| 1991-2004 | GMC Sonoma |
| 1991 | GMC Syclone |
| 2006-2010 | Hummer H3 |
| 2009-2010 | Hummer H3T |
| 2003-2008 | Isuzu Ascender |
| 1996-1998 | Isuzu Hombre |
| 1981-1995 | Isuzu Pickup |
| 1991-2002 | Isuzu Rodeo |
| 2001-2002 | Isuzu Rodeo Sport |
| 1977-1984 | Oldsmobile 98 |
| 1991-1994 | Oldsmobile Bravada |
| 1996-2004 | Oldsmobile Bravada |
| 1977-1991 | Oldsmobile Custom Cruiser |
| 1977-1981 | Oldsmobile Cutlass |
| 1985-1987 | Oldsmobile Cutlass |
| 1978-1984 | Oldsmobile Cutlass Calais |
| 1982-1987 | Oldsmobile Cutlass Ciera |
| 1980-1983 | Oldsmobile Cutlass Cruiser |
| 1987 | Oldsmobile Cutlass Cruiser |
| 1977-1980 | Oldsmobile Cutlass Salon |
| 1985-1987 | Oldsmobile Cutlass Salon |
| 1977-1988 | Oldsmobile Cutlass Supreme |
| 1977-1985 | Oldsmobile Delta 88 |
| 1976-1979 | Oldsmobile Omega |
| 1975-1986 | Pontiac Bonneville |
| 1975-1981 | Pontiac Catalina |
| 1977-2002 | Pontiac Firebird |
| 1978-1980 | Pontiac Grand Am |
| 1977-1983 | Pontiac Grand LeMans |
| 1977-1987 | Pontiac Grand Prix |
| 1975-1978 | Pontiac Grand Safari |
| 1977-1981 | Pontiac Laurentian |
| 1977-1981 | Pontiac LeMans |
Specifications
- GTIN
- 00698231983270
- Weight
- 14.25 lb
- Height
- 5.25 in
- Length
- 15 in
- Width
- 11 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- EXL
- Warehouse brand code
- EXL
- AAIA brand code
- GGVJ
Attributes
- AAM Long Description
- Ring and Pinion
- AAM Short Description
- Ring and Pinion
- App/Model
- GM 7.625"
- Axle Type
- GM 7.5 in.
- California Proposition 65
- WARNING: Cancer - www.P65Warnings.ca.gov
- Cover Bolt Quantity
- 10
- Differential Carrier Break
- 3.08 Ratio and Lower
- Differential Case Design Type
- GM 7.6 IFS
- Gear Ratio
- 4.56
- Mounting Location
- Rear
- Pinion Gear Tooth Quantity
- 9
- Pinion Shaft Diameter
- 1.438
- Pinion Spline Count
- 27
- Position
- Rear
- Ratio
- 4.56
- Ring & Pinion Gear Ratio
- 4.56
- Ring Gear Bolt Quantity
- 10
- Ring Gear Diameter
- 7.5
- Ring Gear Material
- 8620 Steel
- Ring Gear Outside Diameter
- 7.5
- Ring Gear Rotation
- Standard
- Ring Gear Tooth Quantity
- 41
- Ring and Pinion Gear Ratio
- 4.56
- Taxonomy
- GM 7.5/GM 7.625/GM 7.6 IFS
- Taxonomy A
- LD Differential
- Taxonomy B
- Ring and Pinions
- Taxonomy C
- Rear
- Taxonomy D
- 4.56
- Title
- Differential Ring and Pinion
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1973-1975 Buick Apollo; 1977-1981 Buick Century; 1991-1996 Buick Commercial Chassis; 1976-1989 Buick Electra; 1977-1983 Buick Estate Wagon; 1975-1989 Buick LeSabre; 1977-1979 Buick Opel; 1977-1987 Buick Regal; 1977-1978 Buick Riviera; 1991-1996 Buick Roadmaster; 1975-1979 Buick Skylark; 1987-1990 Cadillac Brougham; 1982-1984 Cadillac DeVille; 1982-1990 Cadillac Fleetwood; 1985-2005 Chevrolet Astro; 1995-2005 Chevrolet Blazer; 1977-2002 Chevrolet Camaro; 1977-1996 Chevrolet Caprice; 2004-2013 Chevrolet Colorado; 1991-1994 Chevrolet Commercial Chassis; 1977-1987 Chevrolet El Camino; 1977-1985 Chevrolet Impala; 1994-1996 Chevrolet Impala; 1975 Chevrolet Malibu; 1978-1983 Chevrolet Malibu; 1978-1988 Chevrolet Monte Carlo; 1976-1979 Chevrolet Nova; 1982-2004 Chevrolet S10; 1983-1994 Chevrolet S10 Blazer; 1982-1987 GMC Caballero; 2004-2012 GMC Canyon; 2002-2005 GMC Envoy; 2002-2005 GMC Envoy XL; 2004-2005 GMC Envoy XUV; 1992-2005 GMC Jimmy; 1982-1990 GMC S15; 1983-1991 GMC S15 Jimmy; 1985-2005 GMC Safari; 1991-2004 GMC Sonoma; 1991 GMC Syclone; 2006-2010 Hummer H3; 2009-2010 Hummer H3T; 2003-2008 Isuzu Ascender; 1996-1998 Isuzu Hombre; 1981-1995 Isuzu Pickup; 1991-2002 Isuzu Rodeo; 2001-2002 Isuzu Rodeo Sport; 1977-1984 Oldsmobile 98; 1991-1994 Oldsmobile Bravada; 1996-2004 Oldsmobile Bravada; 1977-1991 Oldsmobile Custom Cruiser; 1977-1981 Oldsmobile Cutlass; 1985-1987 Oldsmobile Cutlass; 1978-1984 Oldsmobile Cutlass Calais; 1982-1987 Oldsmobile Cutlass Ciera; 1980-1983 Oldsmobile Cutlass Cruiser; 1987 Oldsmobile Cutlass Cruiser; 1977-1980 Oldsmobile Cutlass Salon; 1985-1987 Oldsmobile Cutlass Salon; 1977-1988 Oldsmobile Cutlass Supreme; 1977-1985 Oldsmobile Delta 88; 1976-1979 Oldsmobile Omega; 1975-1986 Pontiac Bonneville; 1975-1981 Pontiac Catalina; 1977-2002 Pontiac Firebird; 1978-1980 Pontiac Grand Am; 1977-1983 Pontiac Grand LeMans; 1977-1987 Pontiac Grand Prix; 1975-1978 Pontiac Grand Safari; 1977-1981 Pontiac Laurentian; 1977-1981 Pontiac LeMans; ...
