Dualoy Diesel Pistons · 7199DKT.1.0MM
Part #: 7199DKT.1.0MM
UPC: 800745256539
Loading...
Notify me when this item is in stock.
Description: DUALOY - Cummins 369CI/5.9L
Description:
Description
DUALOY - Cummins 369CI/5.9L
Features & benefits
- Iron ring insert in top groove. Keystone top ring. B Series 12 valve.
Application summary
| Year | Make / model |
|---|---|
| 1995 | Dodge Ram 2500 |
| 1997-1998 | Dodge Ram 2500 |
Specifications
- GTIN
- 00800745256539
- Weight
- 20 lb
- Height
- 5 in
- Length
- 17.75 in
- Width
- 10 in
- Life cycle
- Available to Order
- AAM brand code
- DDP
- Warehouse brand code
- JCLJ
- AAIA brand code
- JCLJ
Attributes
- Alloy
- Cast KSA-1295
- Base Number
- 7199D
- Bore (in)
- 4.015
- Bore (mm)
- 102.0
- Bore Diameter
- 4.015
- Compression Ratio
- 17.5
- Crown (cc)
- +44.2cc
- Crown Type
- CONTOURED HEAD
- Cylinder Bore Diameter
- 4.015
- Eng. Disp Liters
- 5.9
- Eng. Disp. In.
- 369
- Eng. Disp. Liters
- 5.9
- Engine Family
- Cummins
- Engine Manufacturer
- Dodge
- Includes Ring Set
- 20014.1.0MM
- Includes Ring Set Part Number
- 20014.1.0MM
- Model
- Truck
- Oe Assembly
- 3802493
- Oversize
- 1.0mm
- Oversized
- Yes
- Oversizes
- STD .50mm .75mm 1.0mm
- Pin Configuration
- Centered
- Pin Diameter (in)
- 1.575
- Pin Diameter (mm)
- 40.0
- Pin Number
- 7195D-PP
- Pin Type
- Floating
- Ring Pack
- 3.0K, 2.35mm, 4.0mm
- Rod (in)
- 7.56
- Rod (mm)
- 191.97828
- Sold As
- Complete Piston and Ring Kit
- Stroke (in)
- 4.724
- Stroke (mm)
- 120.0
- Top Land
- .318
- Vin Code
- D
- Year From
- 1994
- Year Range
- 1994-1998
- Year To
- 1998
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1995 Dodge Ram 2500; 1997-1998 Dodge Ram 2500
Equivalent Parts
Dualoy Diesel Pistons 7199DKT.1.0MM
