Design Engineering, Inc. · 10472
Part #: 10472
UPC: 607078104724
Loading...
Notify me when this item is in stock.
Description: Fire Sleeve & Tape Kit 5/8in x 36in; One 36 inch length of Fire Sleeve with a 5/8 inch inside diameter and one 1 inch by 2 foot roll of silicone tape.
Description:
This part number superseded 010485.
Description
Fire Sleeve solves the problem of heat and abrasions damaging fuel, transmission and brake lines and is a fireproof solution. Constructed from a high temperature resistant braided glass material, woven into a sleeve and heavily coated with 100% iron oxide silicone rubber, Fire Sleeve thermal insulator sleeve provides the ultimate in heat insulation and protection from direct heat up to 500F. Includes a 16-inch length of black Fire Tape, an adhesive-free, self-adhering tape, to finish off ends of Fire Sleeve or when joining two Fire Sleeves together while presenting a clean and professional look. Insulates wiring, hoses, oil / brakes / transmission lines & more Use for bundling & protecting hoses, electrical wiring, etc. Withstands 2000F of intermittent heat Includes 16 inches of black Fire Tape Size: 0.625 (5/8) inch x 36 inches
Features & benefits
- 5/8 in. x 3 ft Length Of Fire Sleeve
- Includes 16 In. Length Of Fire Tape
- Insulates Wiring/Hoses/Oil/Brake/Transmission Lines And More
- Withstands 500 Degrees F Continuous/2000 Degrees F Intermittent Heat
- Burn Protection During Under Hood Repairs And Maintenance
- Use For Bundling And Protecting Hoses/Electrical Wiring etc.
Information
Fire Sleeve solves the problem of heat and abrasions damaging fuel, transmission and brake lines and is a fireproof solution. Constructed from a high temperature resistant braided glass material, woven into a sleeve and heavily coated with 100% iron oxide silicone rubber, Fire Sleeve thermal insulator sleeve provides the ultimate in heat insulation and protection from direct heat up to 500F. Includes a 16-inch length of black Fire Tape, an adhesive-free, self-adhering tape, to finish off ends of Fire Sleeve or when joining two Fire Sleeves together while presenting a clean and professional look. Insulates wiring, hoses, oil / brakes / transmission lines & more Use for bundling & protecting hoses, electrical wiring, etc. Withstands 2000F of intermittent heat Includes 16 inches of black Fire Tape Size: 0.625 (5/8) inch x 36 inches
Specifications
- GTIN
- 00607078104724
- Weight
- 0.52 lb
- Height
- 1.5 in
- Length
- 7.25 in
- Width
- 5.25 in
- Life cycle
- Available to Order
- AAM brand code
- DEI
- Warehouse brand code
- DEI
- AAIA brand code
- BGWZ
Attributes
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Case Included
- No
- Color
- Black
- Direct Heat Resistance
- 500°F
- ID Metric
- 16 mm
- Includes
- One 36 inch length of Fire Sleeve with a 5/8 inch inside diameter and one 1 inch by 2 foot roll of silicone tape.
- Length
- 36
- Material
- Black Silicone over Glass Fiber
- Maximum Diameter
- 16
- Minimum Diameter
- 16
- Radiant Heat Resistance
- 2000°F
- Title
- DEI 10472 Fire Sleeve & Tape Kit 0.625" ID x 36" 010472
- Tube Wall Thickness
- .125
- Waterproof
- No
Fitment status
This product is universal and will fit your application.
Resources
- Brand logo
- Installation Instructions
- Photo - Lifestyle View
- Photo - Lifestyle View
- Photo - Lifestyle View
- Photo - Lifestyle View
- Photo - Lifestyle View
- Photo - Lifestyle View
- Photo - Primary
- Photo - Close Up
- Photo - Mounted
- Photo - Unmounted
- Photo - Unmounted
- Link To Manufacturer Page
- Regulatory Content Label
- Fire Sleeve Wrap 3000 from Design Engineering, Inc.
- Custom Asset
Equivalent Parts
Design Engineering, Inc. 10472
