Dart / 31181135
Part #: 31181135
UPC: 807051045161
Loading...
Notify me when this item is in stock.
Description: Dart Little M2 Iron Small Block Chevy Blocks
Description:
Description
True race block which will work with most standard components. Provisions for wet or dry sump oiling systems. Great for power adders and maximum effort engines. The Dart Little M2 is designed from the ground up as a true racing engine block which can be used with standard off the shelf small block components. The Little M2 is cast from premium high strength Iron and beefed up in all the critical areas.? A competition oiling system ensures adequate lubrication to the main bearings at high RPM.
Features & benefits
- Uses standard small block parts, including cam, oil pump, oil pan, oil filter, motor mounts, mechanical fuel pump, and clutch linkage
- Billet steel 4-bolt main bearing caps on all 5 mains
- Standard oil pan rail width
- Oil gallery holes machined for O-ring plugs
- Parts kit included
- Priority main oiling system feeds main bearings first
- Center lifter oil crossover for improved lifter oiling
- Siamese cylinder bores with extra thick walLS2 resist cracking and improve ring seal for more power (minimum .275 thick with 4.185 bore)
- Open lifter valley improves oil return to pan
- Enlarged lifter bosses accommodate offset and oversize lifters
- Blind head bolt holes don't go through to water jacket
Information
Dart Little M2 Iron Small Block Chevy Blocks
Specifications
- GTIN
- 00807051045161
- Weight
- 235 lb
- Height
- 14 in
- Length
- 24 in
- Width
- 19 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- DAR
- Warehouse brand code
- BGWK
- AAIA brand code
- BGWK
Attributes
- California Proposition 65
- WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
- Camshaft Lifter Bore
- 0.842
- Camshaft Location
- Raised 0.391 IN
- Category
- Engine Blocks and Accessories
- Category Hierarchy
- Blocks>Small Block Chevy>Little M2 Blocks
- Cylinder Bore Diameter
- 4.000
- Deck Height
- 9.500
- EBAY Category ID
- 33613
- Engine
- Small Block
- Engine - Web
- Small Block
- Engine Block Series
- Little M2
- Engine Type
- ICE
- Industry
- Automotive
- Main Bearing Type
- Chevrolet 350
- Main Cap Type
- Steel
- Make
- Chevrolet
- Make - Web
- Chevrolet
- Product Type
- Engine Block
- Series
- SBC Little M2 Iron Engine Blocks
- Subcategory
- Engine Blocks
- Title
- Little M2 Chevy Small Block Iron Block - 4.000 in. Bore, 9.500 in. Deck
- Title - Web
- Little M2 Chevy Small Block Iron Block - 4.000 in. Bore, 9.500 in. Deck
Fitment status
This product is universal and will fit your application.
