Centerforce · DF026030
Part #: DF026030
UPC: 788442030624
Log in for inventory
Notify me when this item is in stock.
Description: Dual Friction(R), Clutch Pressure Plate and Disc Set; The Centerforce Dual Friction(R) Clutch Series uses patented technologies for an ultimate pressure plate and disc combination.
Description:
Description
The Centerforce(R) Dual Friction(R) Clutch Series is a performance matched pressure plate & disc combination featuring the patented Centerforce centrifugal weight system (where applicable) and specialized machining processes to provide a performance clutch that offers exceptional street characteristics, while offering outstanding holding-capacity and durability. Furthermore, the Centerforce Dual Friction disc has an organic full facing on one side for longevity and an organic segmented facing on the other side providing increased holding capacity. Some applications have the organic segmented facings of both sides. The Dual Friction clutch is engineered for those who are looking for the ultimate in street/strip holding power and performance without sacrificing pedal effort and driver control. While the Dual Friction has been engineered primarily as a street clutch it can be used in mild competition applications.
Application summary
| Year | Make / model |
|---|---|
| 1963-1969 | Ford Fairlane |
| 1964-1970 | Ford Falcon |
| 1967 | Ford Galaxie |
| 1968-1971 | Ford Galaxie 500 |
| 1975-1980 | Ford Granada |
| 1973-1977 | Ford Maverick |
| 1964-1973 | Ford Mustang |
| 1970-1971 | Ford Ranchero |
| 1969-1973 | Ford Torino |
| 1963-1964 | Mercury Comet |
| 1966-1969 | Mercury Comet |
| 1971-1977 | Mercury Comet |
| 1967-1969 | Mercury Cougar |
| 1975-1980 | Mercury Monarch |
| 1969-1973 | Mercury Montego |
| 1978 | Mercury Zephyr |
Specifications
- GTIN
- 00788442030624
- Weight
- 20.25 lb
- Height
- 4 in
- Length
- 14 in
- Width
- 14 in
- EO
- Legal US
- Life cycle
- Available to Order
- AAM brand code
- CEN
- Warehouse brand code
- CEN
- AAIA brand code
- BDPL
Attributes
- Alignment Tool Included
- Yes
- California Proposition 65
- WARNING: Cancer - www.P65Warnings.ca.gov
- Centrifugal Weights
- Y
- Clutch Bolt Pattern
- 4
- Clutch Disc Diameter
- 254.0
- Counterweight Assist
- YES
- Disc Material
- Organic/Carbon Composite
- Disc Type
- Full face/Segmented face
- Disc Type Sprung Solid
- Sprung
- Flywheel Step Type
- Flat
- Includes
- Pressure Plate, Disc, Alignment Tool
- Input Shaft Diameter
- 1-1/8
- Input Spline Quantity
- 26
- Made In The USA
- Assembled
- Material
- Cast Iron Pressure Plate / Full Face and Segmented Organic Friction
- Out of Package Weight
- 19.05
- Outside Diameter of Friction Surface (Standard)
- 10 In
- Replaceable Friction Surface
- N
- SFI 1.1 Approved
- N
- Title
- Centerforce Dual Friction ?, High Performance Clutch Pressure Plate and Disc Set, 388 ft/lbs Capacity, 10in Dia., 26-Spline, Fits Ford/Mercury Cars and Trucks 6/8 Cyl
- Torque Capacity
- 388
Fitment status
Select a vehicle or engine to see whether this part applies to your application.
Application summary
1963-1969 Ford Fairlane; 1964-1970 Ford Falcon; 1967 Ford Galaxie; 1968-1971 Ford Galaxie 500; 1975-1980 Ford Granada; 1973-1977 Ford Maverick; 1964-1973 Ford Mustang; 1970-1971 Ford Ranchero; 1969-1973 Ford Torino; 1963-1964 Mercury Comet; 1966-1969 Mercury Comet; 1971-1977 Mercury Comet; 1967-1969 Mercury Cougar; 1975-1980 Mercury Monarch; 1969-1973 Mercury Montego; 1978 Mercury Zephyr
