Rancho · RS5150

Rancho RS5150

Part #: RS5150
UPC: 039703515009

Loading...
Notify me when this item is in stock.

Brand: Rancho
Log in to order

Description: RS5000 Shock Absorber; Rancho RS5150 Shock Absorber

Description:

This part number has been superseded by RS55150.

Description

The shock that started it all! Rancho RS5000 series has been the shock of choice for light trucks and sport utility vehicles since 1985. Available for stock and lifted applications, RS5000 is ideal for on and off-road use, at an affordable price. Covered by Rancho's limited lifetime warranty.

Features & benefits

  • Ten-stage velocity sensitive valving - Provides tuning specific for each vehicle
  • 5/8-in. (16mm) diameter piston rod (select applications) - Adds strength and durability. Size varies by application.
  • 1 3/8-in. (35mm) diameter piston (select applications) - Ensures performance in any environment
  • Protective boot included - Protects the shock rod and oil seal
  • Limited Lifetime Warranty - Guarantees your investment
  • Limited Lifetime Warranty

Information

Twin-Tube Construction; 10-Stage Velocity Sensitive Valving; 5/8in. Diameter Chrome Piston Rod; 1-3/8in. Diameter Piston; Protective Boot Included; Limited Lifetime Warranty

Application summary

Year Make / model
1999-2000 Cadillac Escalade
1990-2005 Chevrolet Astro
1992-1994 Chevrolet Blazer
1988-1999 Chevrolet K1500
1992-1999 Chevrolet K1500 Suburban
1988-2000 Chevrolet K2500
1992-1999 Chevrolet K2500 Suburban
1988-2000 Chevrolet K3500
1995-2000 Chevrolet Tahoe
1989-1991 Chevrolet V3500
1988-1999 GMC K1500
1992-1999 GMC K1500 Suburban
1988-2000 GMC K2500
1992-1999 GMC K2500 Suburban
1988-2000 GMC K3500
1990-2005 GMC Safari
1988-1991 GMC V3500
1992-2000 GMC Yukon

Specifications

GTIN
00039703515009
Weight
4.75 lb
Height
3.31 in
Length
24.25 in
Width
3.31 in
EO
Legal US
Life cycle
Obsolete
AAM brand code
RAN
Warehouse brand code
RAN
AAIA brand code
BCKM

Attributes

Adjustable
No
Adjustable Length
No
Body Diameter
2.188
California Proposition 65
No
Collapsed Length
11.640 in.
Collapsed Length (in.)
11.640
Compressed Bumper Stop
No
Compressed Length
11.64
Cylinder Included
No
Dust Shield
Yes
Dust Shield Included
Yes
Extended Bumper Stop
No
Extended Hydraulic Lockout
No
Extended Length
16.79
Extended Length (in.)
16.790 in.
Finish
Painted
Fully Open Length
16.790 in.
Lower Mount Type
Loop Bushing & Sleeve Mount - 1/2" Sleeve ID X 1.5/8" Sleeve OAL
Lower Mounting Code
Loop Bushing & Sleeve Mount - 0.500 in. Sleeve ID x 1.625 in. Sleeve OAL
Lower Mounting Description
Loop Bushing Sleeve Mount - 1/2 Sleeve ID x 1.5/8 Sleeve OAL
Max Year Covered
2005
Min Year Covered
1988
Most Popular Make / Model
Chevrolet K1500
Most Popular Make/Model
Chevrolet K1500
Most Popular Year
1998
Parts Pack(s)
None
Product Grade
Premium
Reserve Tube Diameter
2.188 in.
Shock Stroke
5.150 in.
Shock Stroke (in.)
5.150
Total Part VIO
2251049
Travel Length
5.15
Upper Mount Type
Loop Bushing & Sleeve Mount - 1/2" Sleeve ID X 2.7/16" Sleeve OAL
Upper Mounting Code
Loop Bushing & Sleeve Mount - 0.500 in. Sleeve ID
Upper Mounting Description
Loop Bushing Sleeve Mount - 1/2 Sleeve ID x 2.7/16 Sleeve OAL

Fitment status

Select a vehicle or engine to see whether this part applies to your application.

Application summary

1999-2000 Cadillac Escalade; 1990-2005 Chevrolet Astro; 1992-1994 Chevrolet Blazer; 1988-1999 Chevrolet K1500; 1992-1999 Chevrolet K1500 Suburban; 1988-2000 Chevrolet K2500; 1992-1999 Chevrolet K2500 Suburban; 1988-2000 Chevrolet K3500; 1995-2000 Chevrolet Tahoe; 1989-1991 Chevrolet V3500; 1988-1999 GMC K1500; 1992-1999 GMC K1500 Suburban; 1988-2000 GMC K2500; 1992-1999 GMC K2500 Suburban; 1988-2000 GMC K3500; 1990-2005 GMC Safari; 1988-1991 GMC V3500; 1992-2000 GMC Yukon
Retail View

Equivalent Parts

Rancho - RS55150
